User Guide

ANT.IN
VCR
AV-1
AV-2
QUICK GUIDE
IMPORTANT - If plac i ng TV into cabinet or alcove, ensure the re is at least a 100m m ( 10cm) gap to the si des,
rear and top of the TV. This is to allow for adequate ventilation during operation. Please read the
ma in Users Guide for mor e saf ety inf or m at i on before i nstal la ti o n.
insert the batteries into your handset
either connect the aerial straight to y our TV...
...or connect the aerial through a VCR...
Aerial (RF) Socket
Aerial (RF) Socket
wall
socket
wall
socket
Aerial (RF)
Lead
Aerial (RF)
Lead
Optional Scart Lead
TV to VCR
Aerial (RF) Socket VCR
(RF) connector
lead VCR to TV
• It is recommended that a scart lead should be fitted between your TV and VCR to enhance your picture and sound
quality. Scart leads are essential if you have a stereo TV and VCR and wish to obtain stereo sound from your
equipment. These leads can be purchased from your Hitachi dealer or any good High Street electrical retailer.
37LD8700U
TFT-LCD TV
GB
Scart 2Scart 1
Scart 2Scart 1
