Operation Manual

Installing Batteries in the Remote Control
1. Slide the back cover to open the battery compartment of the remote control.
2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in
the battery compartment.
3. Close the battery compartment cover.
1. Dispose of your batteries in a designated disposal area. Do not throw the batteries into fire.
2. Do not mix battery types or combine used batteries with new ones.
3. Remove depleted batteries immediately to prevent battery acid from leaking into the battery
compartment.
4. If you do not intend to use the remote control for a long time, remove the batteries.
5. The effective range of remote control is suggested in the figure below.
Remote Control Operation Range
Point the remote control at the TV no more than 8 metres
from the remote control sensor on the TV and within 60° in
front of the TV and 30° in the vertical angle.
The operating distance may vary depending on the
brightness of the room.
15
Remote Control
30° 30°
8M
15°
8M
15°
NOTE
1
Gently push and slide
2
Insert the batteries
3
Gently push and slide
Match the Remote Control with TV
Aim your remote control within 4 inches of the lower left
corner of your TV. Press the [EPG] and [LAST] buttons
simultaneously for at least 3 seconds. The LED at the top of
your remote will light for one second and blink slowly three
times to indicated the remote has paired with the TV.
NOTE
If the LED does not turn on, the remote has failed to pair
with the TV, repeat the pairing procedure.
3D
Still
Zoom
Text
PVR
Exit
Sound
Source
CH
VOL
Info
Menu
Sleep
Last
Return
OK
Mute
Subtitle
AudioI/II
T.shift
DMP
EPG
Mix
Size
HiSmart@
