6 English 2221133
*2221133*
▶ Use only Hilti battery chargers of the C4/36 series for these batteries.
3.4 Lithiumion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are indicated by the display on the Liion
battery. The Liion battery state of charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. State of charge: 75 % to 100 %
3 LEDs light. State of charge: 50 % to 75 %
2 LEDs light. State of charge: 25 % to 50 %
1 LED lights. State of charge: 10 % to 25 %
1 LED flashes. State of charge: < 10 %
1 LED flashes, the power tool is not in working or-
der.
The battery has overheated or is completely dis-
charged.
4 LEDs flash, the power tool is not in working or-
der.
The power tool is overloaded or has overheated.
Battery state of charge cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs flash, please observe the instructions given in the Troubleshooting section.
4 Technical data
CD 4A22
Weight, aluminum tube
3.6 kg
(7.9 lb)
Weight, cartridge holder
3.2 kg
(7.1 lb)
Speed regulation
1 mm/s … 10 mm/s
(0.04 in/s … 0.4 in/s)
4.1 Battery
Battery operating voltage
21.6 V
Ambient temperature for operation
−17 ℃ … 60 ℃
(1 ℉ … 140 ℉)
Storage temperature
−20 ℃ … 40 ℃
(−4 ℉ … 104 ℉)
Battery charging starting temperature
−10 ℃ … 45 ℃
(14 ℉ … 113 ℉)
5 Preparations at the workplace
5.1 Preparations at the workplace
CAUTION
Risk of injury by inadvertent starting!
▶ Before inserting the battery, make sure that the product is switched off.
▶ Remove the battery before making any adjustments to the power tool or before changing accessories.
Observe the safety instructions and warnings in this documentation and on the product.
5.1.1 Charging the battery
1. Before charging the battery, read the operating instructions for the charger.
2. Make sure that the contacts on the battery and the contacts on the charger are clean and dry.
