Network Traffic Camera • Quick Start Guide
8
Rear Panel Interface
Interface
Description
LAN1/LAN2
10/100/1000 M Ethernet interface
TF
TF card slot
PWR
Power indicator
Ground
RTG
RS-232 interface for debugging and temperature shield control via
transparent channel.
D1-D3
RS-485 interface, for transferring RS-485 input information (such as
radar, vehicle detector, etc.).
SYNC
Synchronization input
T1
Input trigger
F1-F7
Flash light trigger output
USB
USB interface
12 VDC
12 VDC power input
The USB interface can only be connected to USB flash drive. It is not allowed to charge other
devices or connect other loads.
