Data Sheet


Specification
Camera
Image Sensor
1/1.8" Progressive Scan CMOS
Min. Illumination
Color: 0.009 Lux @ (F1.2, AGC ON); B/W: 0.0009 Lux @ (F1.2, AGC ON)
Shutter Speed
1 s to 1/100,000 s
Slow Shutter
Yes
P/N
P/N
Wide Dynamic Range
120 dB
Day & Night
IR cut filter
Power-off Memory
Yes
Lens
Focus
Auto, semi-auto, manual
Lens Type & FOV
2.8 to 12 mm, horizontal FOV: 112.3° to 41.2°, vertical FOV: 58° to 23.1°, diagonal FOV:
137.3° to 47.3°
8 to 32 mm, horizontal FOV: 41.8° to 14.9°, vertical FOV: 22.92° to 8.48°, diagonal FOV:
48.7° to 17°
Aperture
2.8 to 12 mm: F1.2 to F2.5
8 to 32 mm: F1.7 to F1.73
Lens Mount
Integrated
Blue Glass Module
Blue glass module to reduce ghost phenomenon.
P-Iris
Yes
Illuminator
IR Range
2.8 to 12 mm: 50 m
8 to 32 mm: 100 m
Wavelength
850 nm
Smart Supplement Light
Yes
Video
Max. Resolution
3840 × 2160
Main Stream
50Hz: 25 fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
50Hz: 25 fps (704 × 576, 640 × 480)
60Hz: 30 fps (704 × 480, 640 × 480)
Third Stream
50Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream
50Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream
50Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/ H.264
Sub-stream/Third stream/Fourth stream/Fifth stream/custom stream:
H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 16 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
H.264+
Main Stream supports
H.265+
Main Stream supports
Bit Rate Control
CBR/VBR
Stream Type
Main stream/sub-stream/third stream/fourth stream/fifth stream/custom stream
