Data Sheet

Web Client Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),Ukrainian
General Function
Anti- flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy
masks, flash log, password reset via e-mail, pixel counter
Software Reset
Yes
Storage Conditions
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating
Conditions
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 20%, three-core terminal block, reverse polarity protection; PoE
:
802.3at,
Type 2 Class 4
Power Consumption and
Current
12 VDC, 1.33 A, max. 16.0 W
PoE: (802.3at, 42.5V-57V), 0.43 A to 0.31 A, max. 18.0 W
Power Interface
3-core terminal block
Camera Material
Aluminum alloy body
Camera Dimension
Without -Y: Ø144 × 347 mm (Ø5.7″ × 13.7″)
With -Y: Ø140 × 351 mm (Ø5.5″ × 13.8″)
Package Dimension
405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
Camera Weight
1920 g (4.2 lb.)
With Package Weight
3060 g (6.7 lb.)
Metadata
Metadata
Metadata of intrusion detection, line crossing detection, region entrance detection,
region exiting detection, unattended baggage detection, object removal, face capture
and queue management are supported.
Approval
Class
Class B
EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN
61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
(ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1:2009 + Am 2: 2013); CE-LVD (EN
60950-1: 2005 + Am 1: 2009 + Am 2:2013); BIS (IS 13252(Part 1): 2010+A1: 2013+A2:
2015); LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
Automotive and Railway
With -R: EN50121-4
Anti-Corrosion Protection
With -Y: NEMA 4X(NEMA 250-2018)
Other
With -Y: PVC FREE
Available Model
iDS-2CD7A26G0-IZHS (2.8 to 12 mm), iDS-2CD7A26G0-IZHS (8 to 32 mm), iDS-2CD7A26G0-IZHSY (2.8 to 12 mm),
iDS-2CD7A26G0-IZHSY (8 to 32 mm), iDS-2CD7A26G0-IZHSYR (2.8 to 12 mm) iDS-2CD7A26G0-IZHSYR (8 to 32 mm)
