Data Sheet

Specification
Model
DS-MP5604-SD
Video/Audio Input
Analog Camera
4 analog cameras, up to 1080p resolution
IP Camera
1 IP camera, up to 1080p resolution
Two-way Audio
1, integrated in EXT.DEV interface
Video/Audio
Output
Video Output
Main output: 1, integrated in EXT.DEV interface
Audio Output
1
Encoding/Decoding
Parameters
Video Compression
H.264/H.265
Encoding Resolution
Main stream: 1080p/720p/WD1/4CIF
Sub-stream: 4CIF/2CIF/CIF
Frame Rate
● PAL: 1 to 12 fps@1080P; NTSC: 1 to 12 fps@1080P;
● PAL: 1 to 25 fps@720P; NTSC: 1 to 30 fps@720P
Audio Compression
G.711/G.722.1
Stream Type
Video, video & audio
Audio Bitrate
16 Kbps
Dual Stream
Supported
Storage
SD Card
2 × SD card, up to 256 GB
Wireless Network
3G/4G Dialing
1 × 3G/4G card slot, 1 × Rosenberger antenna
Wi-Fi
● WI58 model: 2 × 5.8 G Wi-Fi SMA antenna
● WI model: 1 × 2.4 G Wi-Fi SMA antenna
Positioning
GNSS (Global Navigation
Satellite System)
GPS (Global Positioning System) & GLONASS (Global Navigation Satellite System), 1
× Rosenberger antenna
External Interface
Network Interface
1 × 10M/100M M12 6-pin aviation connector
(2 pins are for 12 VDC power supply. 4 pins are for LAN connection. The network
interface can be extended to connect 1-ch IP camera. The max. consumption is 6
W.)
Serial Port
1 × RS-232, 1 × RS-422 (integrated in EXT.DEV interface)
USB Interface
1 × USB 2.0
Sensor-in
4 high/low level signal inputs
Alarm Input
4 high/low level signal inputs, 1 pulse signal input, 1 BUTTON input
Alarm Output
2 relay signal outputs
General
Operating Method
Mouse, IR remote control, Web control, and touchscreen
Power Supply
9 to 32 VDC
Consumption
● Standby: ≤ 0.5 W
● Full load: ≤ 45 W
Note: Without peripheral and storage media ≤ 20 W
Working Temperature
-10 °C to +60 °C (+14 °F to +140 °F)
Working Humidity
10% to 95%
Dimension (W × D × H)
184 × 142.6 × 44 mm (7.2 × 5.61 × 1.73 inch)
Weight (Without Storage
Media)
0.8 kg (1.8 lb)
