Quick Start Guide

Video Intercom Door Station·Quick Start Guide
20
 When the video intercom between you and the resident is realized, you can speak to
the resident, and the live view of door station will be displayed on the connected
indoor station.
 When live view of door station is displayed on other devices or door station is calling
resident, the door station will detect the brightness of video. When the brightness is
lower than the expected threshold, the supplement light will be enabled.
 When the supplement light is enabled, the backlight of key will be auto-enabled,
otherwise, the door station will detect the brightness of live view and enable the
backlight of key when the brightness of live view is lower than expected threshold.
6.1.2 Calling Resident (DS-KV8102-XP)
You can call the resident by pressing the call button. For device DS-KV8102-IP/VP, there
is only 1 call button.
 Default settings of call button: when you press the call button, it calls the resident;
and when you hold down the call button, it calls the center.
 You can change the calling mode of the call button via Batch Configuration Tool or
iVMS-4200 client software. See User Manual for detail steps.
Figure 6-2 Call Button of DS-KV8102-XP
Steps:
1. Press the corresponding call button of the resident.
2. The resident can receive/decline the video call, unlock the door, call the elevator, etc.
