Video Intercom Indoor Station·User Manual
19
Slide left and right to realize the switch between two interface pages (except for
DS-KH6210-L.
Here the user interface of DS-KH8301-WT is taken as as example.
Only DS-KH8301-WTS/DS-KH8301-WT/DS-KH8300-T indoor stations support TF card.
DS-KH6210-L only has one interface page.
Figure 7-4 User Interface of DS-KH6210-L
7.2.2 User Interface of Indoor Extension
Figure 7-5 User Interface of Indoor Extension
Only DS-KH8301-WTS/DS-KH8301-WT/DS-KH8300-T indoor extensions support TF
card.
Here the user interface of DS-KH8301-WT indoor extension is taken as example.
