Installation Guide

No. Interface Descripon
B6 485+
B7 12 V OUT
B8 GND
C LAN Power and Network Interface
2.2 Wiring Descripon
2.2.1 Power Supply Wiring
Cauon
Make sure all the related equipment is power-o during the installaon.
Wire the devices with power supply cables as picture shown below.
Door staon should be connected to CH6 of the video/audio distributor with two-
wire cables.
Indoor Staon should be connected to any terminal of CH1 to CH5 of the video/
audio distributor with two-wire cables.
