Figure 3-58 Fix the Gang Boxes
8.
Fill and level up the gap between the gang box and wall with concrete. Remove
the mounng ears with tool aer concrete is dry. Pass the grounding line
through the cable entries.
Figure 3-59 Remove the Mounng Ears
Note
The green-yellow line in the package is for grounding.
9.
Connect wires and insert the modules.
1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of
the Main Unit, then place the Main Unit into the upper grid of the
le gang
box.
