Figure 3-24 Mark the Screw Holes
4.
Chisel 4 holes with drill align to marks on the wall, and insert the expansion
sleeves into the screw holes. The suggested size of hole is 6 (diameter) × 45
(depth) mm.
5.
Fix the gang box with 4 expansion bolts.
Figure 3-25 Fix the Gang Box
6.
Fill and level up the gap between the gang box and wall with concrete. Remove
the mounng ears with tool aer concrete is dry.
