Installation Guide

Note
•
The dimension of one-module gang box is: 237(W)×134(H)×56(D) mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Cave the installaon hole, and pull the cable out.The suggested dimension of
installaon hole is 220(W)×108(H)×45.5(D) mm. The suggested length of cables
le outside is 270 mm.
Figure 3-23 Cave the Installaon Hole
2.
Remove the plasc sheet of the cable entry which will be used.
3.
Insert the gang box into the hole and pull out the cables through the cable entry.
Mark the screw holes' posion with a marker, and take out the gang box.
Door
