Installation Guide

Before You Start
Figure 3-15 Mounng Frame
Note
•
The dimension of two-module mounng frame is: 219(W)×107 (H)×32.7(D) mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Paste the
installaon Scker 1 onto the wall. Make sure the scker is placed
leveled via measuring with the gradienter.
2.
Chisel 4 holes with drill align to the screw holes on the
scker. The suggested size
of hole is 6 (diameter) × 25 (depth) mm. The suggested length of cables le
outside is 270 mm.
Door
Staon Installaon Guide
