Installation Guide

Figure 3-9 Cave the Installaon Hole
2.
Remove the plasc sheet in the cable entry.
3.
Insert the gang box into the hole and pull out the cables through the cable entry.
Mark the screw holes' posion with a marker, and take out the gang box.
Figure 3-10 Mark the Screw Holes
4.
Chisel 4 holes with drill align to marks on the wall, and insert the expansion
sleeves into the screw holes.
Note
The suggested size of hole is 6 (diameter) × 45 (depth) mm.
5.
Fix the gang box with 4 expansion bolts.
Door
Staon Installaon Guide
14
