Installation Guide

Figure 3-8 Gang Box
Note
•
The dimension of one-module gang box is: 115(W)×134(H)×56(D) mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Cave the
installaon hole, and pull the cable out.
Note
•
The suggested dimension of installaon hole is 118(L)×108(W)×45.5(D) mm.
•
The suggested length of cables le outside is 100 mm.
Door Staon Installaon Guide
13
