Installation Guide

Note
•
The dimension of one module mounng frame is: 117(W)×107(H)×32.7(D) mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Paste the installaon Scker 1 onto the wall. Make sure the scker is placed
leveled via measuring with the gradienter.
2.
Chisel 4 holes with drill align to the screw holes on the scker.
Note
•
The suggested size of hole is 6 (diameter) × 25 (depth) mm.
•
The suggested length of cables le outside is 100 mm.
Figure 3-3 Chisel Screw Hole
3.
Remove the stricker and insert the expansion sleeves into the screw holes.
4.
Fix the mounng frame onto the wall with 4 expansion bolts.
Door
Staon Installaon Guide
