Figure 2-5 Exit Buon Wiring
Note
AIN3 and AIN4 are set as default for connecng exit buon. Exit buon connected to
AIN3 opens the lock connected to NC1/NO1; Exit buon connected to AIN4 controls
the lock that connected to NC2/NO2.
Door Staon Installaon Guide
