Installation Guide

Note
•
Terminal NC1/COM is set as default for accessing magnec lock/electric bolt;
terminal NO2/COM is set as default for accessing electric strike.
•
Lock should be powered by itself. Max. voltage and current for relay is 30V and
1A.
2.2.3 Door Magnec Wiring
Figure 2-4 Door Magnec Wiring
Note
AIN1 and AIN2 are defaulted to connect door magnec. Door magnec connected to
AIN1 detects status of the lock that connected to NC1/NO1; Door magnec
connected to AIN2 detects the status of the lock connected to NC2/NO2.
2.2.4 Exit Buon Wiring
Door Staon Installaon Guide
6
