Data Sheet

Specification
System parameters
Processor
Embedded MCU Processor
Operation
system
Embedded Linux operation system
Operation
method
Physical button
Video Parameters
Camera
Low illumination 2 MP HD IR camera
Video
Compression
Standard
H.264
Resolution
Main stream : 1920 × 1080
Sub stream : 720 × 480
BLC
Supported
DNR
Supported
WDR
Supported
Anti-flicker
50 Hz, 60 Hz
Field of view
Horizontal: 180° Vertical: 96°
Audio parameters
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker (More than 85 dB
within 20 cm)
Audio
compression
standard
G.711 U
Audio
compression
Rate
64 Kbps
Audio quality
Noise suppression and echo cancellation
Light supplement
Light
supplement
mode
IR supplement
Network parameters
Ethernet
10/100 Mbps self-adaptive Ethernet
Network
protocol
TCP/IP, RSTP
Alarm parameters
Tampering
alarm
1
Interfaces
Module-
connecting
1
Door contact
input
2
Exit button
input
2
I/O input
4
Debug
1
Door control
2, breakdown voltage: 36 V
Performances
Card capacity
Max. 10000
User capacity
Max. 2000
Linked Indoor
station
Max. 100
Linked sub door
station
Max. 8
Linked
doorphone
Max. 8
Protocol
ISAPI, RTSP, STMP, SNMP
Unlock door
Unlock by presenting cards, unlock via
Client Software, unlock via App, unlock via
indoor station
General
Physical button
1
Power supply
12 VDC/PoE (IEEE 802.3af)
Power
consumption
≤ 10 W
Working
temperature
-40° C to +55° C(-40° F to 131° F)
Working
humidity
10% to 95%
Installation
Flush mounting, surface mounting
Dimension
98 mm × 99.8 mm × 43.9 mm (3.86" ×
3.93" × 1.73")
Weight
554 g (with packaging)
375 g (without packaging)
Available Model
DS-KD8003-IME1
Appearance and Interfaces
No.
Description
No.
Description
1
Microphone
6
Nametag
2
Low Illumination IR
Supplement Light
7
TAMPER
3
Built-in Camera
8
Network Interface
4
Loudspeaker
9
Module-connecting
Interface (output)
5
Call Button
10
Terminals
Dimension
