Data Sheet

Specifications
Model
DS-D60C-B
Resolution
1920x1080p@30Hz, 1920x1080p@50Hz, 1920x1080p@60Hz,
1280x720p@30Hz, 1280x720p@50Hz, 1280x720p@60Hz,
3840x2160p@30Hz, 3840x2160p@50Hz, 3840x2160p@50Hz (YCbCr420),
3840x2160p@60Hz, 3840x2160p@50Hz (YCbCr420)
Echo cancellation
No
Interface
HDMI OUT
1-ch
AUDIO IN
1-ch
AUDIO OUT
1-ch
LAN
1
USB
2 x USB 2.0 interface
TF Card Slot
1
Power
12 VDC, 2 A
Working consumption
≤ 20 W
Standby consumption
≤ 1 W
Working temperature
0 °C to 50 °C (32 °F to 122 °F)
Working humidity
10 % to 90 %
Wired network
1000 M/100 M self-adaptive
Wireless network
Wi-Fi 802.11b/g/n
Bluetooth
Bluetooth 4.0
Dimension
Without package
145 mm x 145 mm x 31.89 mm (5.7" x 5.7" x 1.3")
With package
188 mm x 176 mm x 101 mm (7.4" x 6.9" x 4.0")
Weight
Net weight
0.6 kg (1.3 lb.)
Rough weight
0.65 kg (1.4 lb.)
Built-in system
Chip
RK 3288
CPU
4-core Cortex-A17
GPU
Mali T764
Operating
memory
2 GB
Internal memory
8 GB (EMMC), TF Card 32 GB
Operating
system
Android 6.0.1
Accessory
Power Adaptor, Battery, Remote Control, CD-ROM
