Figure 4-4 Receiving Card Version
2. Check receiving card details in the receiving card version interface for device maintenance.
3. Click OK.
4.9 Upgrade
Please use the latest rmware to obtain all possible security updates.
Note
Do not disconnect the power supply during updang.
4.9.1 Local Upgrade
Upgrade Receiving Card/Mul-funconal Card
You can upload upgrade patch to upgrade receiving card or mul-funconal card.
Full-Color LED Display Controller User Manual
31
