Default
The area displays the defalut picture in the system.
Black Screen
The area displays black screen.
Custom
Click Upload to upload pictures to be displayed. You can also replace or delete the uploaded
pictures.
Please upload pictures in JPEG or JPG format with size smaller than 6 MB.
5. Click OK.
3.14
Congure Screen Splicing
You can splice mulple LED screens into one to display a complete picture, without the need for
processing by professional video wall controllers. 3D screen splicing is available.
Steps
1. Click Screen Splicing Conguraon.
Figure 3-18 Screen Splicing Conguraon
2. Congure the sending card splicing scale.
Note
Up to 4 × 4 are available for the splicing scale.
3. Bind devices to the specic display areas. You can use one of the following ways.
-
Click to choose the area, and then click
before the desired device to bind.
-
Drag the desired device to the area to bind.
