3.3.3 Congure Brightness
Congure LED screen brightness.
Steps
1. Click Screen Adjustment → Basic Control → Basic
Conguraon .
Figure 3-9 Brightness Adjustment
2. Adjust the brightness. Brightness ranges from 1 to 8. Brightness of energy saving mode ranges
from 1 to 2. Brightness of balanced mode ranges from 3 to 4. Brightness of high light mode
ranges from 5 to 6. Brightness of sport mode is from 7 to 8.
-
Slide the slider.
-
Enter numbers in the text box.
Brightness
Brightness is a photometric measure of the luminous intensity per unit area of light traveling
in a given
direcon. It describes the amount of light that passes through, is emied or
reected from a parcular area, and falls within a given solid angle. The SI unit for luminance
is candela per square metre (cd/m2).
Note
If the device has congured mul-funconal card, you can check Auto to enable auto brightness
adjustment.
3. Enable Eye Protecon Mode as needed.
3.3.4
Congure Image Enhancement
You can enhance image display eects by client.
Before You Start
Connect the signal resource to the device correctly.
