User Manual

Horizontal Line
Correct all horizontal seams.
5. Select area to correct.
-
Check Show Module and select the module to correct.
-
Uncheck Show Module and select the screen to correct.
6. Drag the bar to adjust Seam Width.
Note
The seam width ranges from 1 to 10.
7. Adjust RGB value.
-
Drag the bars.
-
Enter numbers in the text boxes.
Note
• You can check Simultaneous Adjustment to adjust RGB simultaneously.
• The number ranges from 800 to 1200, and the default value is 1000.
8. Click Preview to check the eects.
9. Click Apply.
Batch Correct Screen
You can correct screen display in a batch by imporng correcon le.
Before You Start
• The correcon le has been obtained from the supplier.
• Select a screen as the start of the batch
correcon in the Manual Correcon .
Steps
1. Click Screen Adjustment → Advanced Operaon → Correcon → Batch Correcon .
Figure 3-7 Batch Correcon
2. Click to select correcon le.
3. Click Upload. The screens/seams will be corrected based on the uploaded le.
Operaon
Descripon
Full-Color LED Display Controller User Manual
14
