User Manual

Figure 3-2 Signal Cable Conguraon
4. Connect signal line.
-
Click the screen on the right side of the interface to connect signal line.
-
Select Line Type, and select
starng port and end port on the right side of the interface.
5. Right-click on the right side of the interface aer connecon.
6. Select Complete Signal Cable Connecon.
7. Click Save.
Port
conguraon informaon set. will pop up aer the signal cable is connected.
Other
Operaon
Supports some auxiliary operaons to complete the signal cable connecon.
Copy Image
Enable Copy Image as needed, and
ll the number of images (the number of screens).
According to the actural lines displayed on screen, congure signal cables in every image/screen
on the client. For more informaon about how to congure signal cables, refer to Congure
Signal Cable .
Table 3-1 Maximum Number of Images for
Dierent Sending Card Type
Sending Card Type Maximum Number of Images
DS-D42C16 8
DS-D42C08 4
DS-D42C04 2
Sending Port
Full-Color LED Display Controller User Manual
9
