1.2 Rear Panel
DS-7100NI-Q1 and DS-7100NI-Q1/M Series
Figure 1-3 DS-7100NI-Q1 Rear Panel
Figure 1-4 DS-7100NI-Q1/M Rear Panel
Table 1-2 Description of Rear Panel
No.
Item
Description
1
Power Supply
12 VDC power supply.
2
VGA Interface
DB9 connector for VGA output. Display local video
output and menu.
3
HDMI Interface
HDMI video output connector.
4
USB Interface
Universal Serial Bus (USB) ports for additional devices
such as USB mouse and USB Hard Disk Drive (HDD).
5
LAN Network Interface
10 /100 Mbps self-adaptive Ethernet interface.
6
Ground
Ground (needs to be connected when NVR starts up).
