Data Sheet

DS-2XM63C5G0-IV(S)(M)(/ND) is a fisheye network camera
capable of providing a 360-degree panoramic image of its
surveillance scene.
The progressive scan CMOS sensor provides high-resolution
images of up to 4000 × 3000.
Up to 15 live view display modes, designed for 3 mount types,
meet various user preference.
Three independently controlled IR lights offer a range of 15 m
and provide good vision in low or even zero-light environment.
DS-2XM63C5G0-IV(S)(M)(/ND)
12 MP IR Network Fisheye Camera
 1/1.7” Progressive Scan CMOS
 Max. 4000 × 3000 @20fps
 Up to 15 live view display modes
 Digital WDR
 Up to 15m IR range
 Built-in microphone
 Smart features
6 behavior analyses, and 1 exception
detection
 Supports hardware dewarping
 Automotive and Railway:
EMARK/EN45545/EN50155-2017/R118
