Spec Sheet

Specifications
Model
Parameter
DS-2TP03-15VM/W
Bi-spectrum Handheld Thermography Camera
Thermal
Module
Image sensor
Uncooled Focal Plane Arrays
Max. Resolution
384 × 288
Detector Pitch
17μm
Response waveband
8μm to 14μm
NETD
< 50mk (@25° C,F#=1.0)
Field of View
25° × 19 °
focal length
15 mm
MRAD
1.13
Aperture
F 1.0
Optional Lens
(not included)
2X Zoom Ratio Lens (FOV: 12° × 10°)
3X Zoom Ratio Lens (FOV: 7° × 5.6°)
1/2X Zoom Ratio Lens (FOV: 46° × 37.6°)
Optical Module
Max. Resolution
1920 × 1080
View (Picture) Resolution
1920 × 1080
Image Display
Monitor
320× 240 resolution 3.5’’ LCD touch display
Pallets
Black hot, White hot, Red hot, Rainbow, Ironbow, Fusion, Rain
Storage
Built-in memory module (64G)
Digital Zoom
2× , 4×
Capture Snapshot
Thermal/Optical/Fusion image
Record Video
Support on-board video recording
Thermography
Rules
Max. Temperature; Min. Temperature; Center Temperature;
Custom Point/Line/Frame Thermometry
Thermometry Range
-20 ° C to 650 ° C (-4 ° F to 1202 ° F)
Thermometry Accuracy
± 2 ° C or ± 2% (Larger Value)
System
Battery Type
Replaceable Lithium Battery
Battery Operating Time
Over four hours continuous running
Battery Capacity Display
Support
Functions
LED Light Supplement
Support
Wi-Fi
Support
Hot Track
Support
AGC
Support (Auto AGC and Manual AGC)
Laser Light
Support (Point to the thermography target)
Picture in Picture
Support (Thermal View in Optical View & Optical View in
Thermal View)
Fusion
Support (Thermal View and Optical View Combined)
General
Power
12 V DC/1.5A, 5V DC/2A (Charging via USB)
Power Consumption
Approx. 5 W (Wi-Fi On), 4.2 W (Wi-Fi Off)
Working Temperature
-20 ° C to 50 ° C (-4 ° F to 122 ° F)
Protection level
IP54
Drop Test Height
2 m (6.56 feet)
Dimension
281 mm × 117 mm × 135 mm (11.1 ″ × 4.6 ″ × 5.3 ″)
Weight
Approx. 1000 g (2.21 lb)
