User's Manual

In the Directory Structure field, you can select the root directory, parent directory and
child directory.
 Root directory: The files will be saved in the root of FTP server.
 Parent directory: The files will be saved in a folder in FTP server. The name of folder can
be defined as shown in Figure 6-9.
Figure 6-9 Parent Directory
 Child directory: It is a sub-folder which can be created in the parent directory. The files
will be saved in a sub-folder in FTP server. The name of folder can be defined as shown
in Figure 6-10.
Figure 6-10 Child Directory
 Upload type: To enable uploading the captured picture to the FTP server.
3. Click to save the settings.
4. You can click Test to confirm the configuration.
Note:
If you want to upload the captured pictures to FTP server, you also have to enable the
continuous snapshot or event-triggered snapshot in Snapshot interface.
Configuring Email Settings
Purpose:
The system can be configured to send an Email notification to all designated receivers if an alarm
event is detected, e.g., motion detection event, video loss, video-tampering, etc.
Before you start:
Configure the DNS Server settings under Configuration> Network > Basic Settings > TCP/IP
before using the Email function.
Steps:
1. Enter the Email settings interface:
Configuration> Network > Advanced Settings > Email
