6. Click to finish drawing or click to clear all of the areas you set without
saving them.
7. Click to save the privacy mask, and it will be listed in the Privacy Mask List area.
8. Modify the mask settings.
Type: you can specify a desired color for the mask or set it as mosaic.
Note:
The mosaic option may not be supported by certain camera models.
Active Zoom Ratio: The set mask is only valid when the camera zoom ratio is equal to
or larger than the set value. Click to check or change current zoom ratio (The
zoom ratio value is displayed on image).
Figure 5-34 Privacy Mask List
5.4.6 Configuring Scheduled Tasks
Purpose:
You can configure the network speed dome to perform a certain action automatically in a
user-defined time period.
Steps:
1. Enter the Scheduled Task settings interface:
Configuration> PTZ > Scheduled Tasks
Figure 5-35 Configure Scheduled Tasks
