Network Speed Dome User Manual
User Manual of Network Speed Dome i User Manual © 2019 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved. This Manual is the property of Hangzhou Hikvision Digital Technology Co., Ltd. or its affiliates (hereinafter referred to as “Hikvision”), and it cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected. Warnings Follow these safeguards to prevent serious injury or death.
Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal damage to the product. The sensor may be burned out by a laser beam, so when any laser equipment is being used, make sure that the surface of the sensor not be exposed to the laser beam. For working temperature, refer to the specification manual for details. To avoid heat accumulation, good ventilation is required for a proper operating environment.
Table of Contents CHAPTER 1 OVERVIEW ................................................................................................................. 1 1.1 SYSTEM REQUIREMENT ............................................................................................................. 1 1.2 FUNCTIONS ............................................................................................................................ 1 CHAPTER 2 2.1 SETTING THE NETWORK CAMERA OVER THE LAN ......................
5.2.1 Configuring Motion Detection ....................................................................................... 43 5.2.2 Configuring Video Tampering Alarm.............................................................................. 48 5.2.3 Configuring Alarm Input................................................................................................ 49 5.2.4 Configuring Alarm Output .............................................................................................
6.4 CONFIGURING SYSTEM SETTINGS ............................................................................................. 112 6.4.1 System Settings........................................................................................................... 112 6.4.2 Maintenance .............................................................................................................. 117 6.4.3 Security ..............................................................................................
User Manual of Network Speed Dome 1 Chapter 1 Overview 1.1 System Requirement System requirement of web browser accessing is as follows: Operating System: Microsoft Windows XP/Win7/Win8/Win10 CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024 × 768 resolution or higher Web Browser: Internet Explorer 8.0 to 11.0, Apple Safari 11.0 and above version, Mozilla Firefox 30.0 and above version, Google Chrome 31.0 and above version, and Microsoft Edge 16.16299 and above version.
automatically adjust in size as the lens zooms telephoto and wide. 3D Positioning In the client software, use the left key of mouse to click on the desired position in the video image and drag a rectangle area in the lower right direction, then the camera system will move the position to the center and allow the rectangle area to zoom in. Use the left key of mouse to drag a rectangle area in the upper left direction to move the position to the center and allow the rectangle area to zoom out.
A time task is a preconfigured action that can be performed automatically at a specific date and time. The programmable actions include: auto scan, random scan, patrol 1-8, pattern 1-4, preset 1-8, frame scan, panorama scan, tilt scan, day, night, reboot, PT adjust, Aux Output, etc. Park Action This feature allows the camera to start a predefined action automatically after a period of inactivity.
4 User Manual of Network Speed Dome Chapter 2 Network Connection Notes: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, strengthen your own protection. If the product does not work properly, contact with your dealer or the nearest service center. To ensure the network security of the network camera, we recommend you to have the network camera assessed and maintained termly.
or C ork tw Ne e abl 网络交换机 Ne two rk C ab le Network Speed Dome Computer Figure 2-2 Connecting via a Switch or a Router 2.1.2 Activating the Camera Purpose: You are required to activate the camera first before you can use the camera. Activation via web browser, activation via SADP, and activation via client software are supported. Activation via Web Browser Steps: 1. Power on the camera, and connect the camera to the network. 2.
4. 5. Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Confirm the password. Click OK to activate the camera and enter the live view interface. Activation via SADP Software SADP software is used for detecting the online device, activating the device, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts.
You can enable the Hik-Connect service for the device during activation. Hik-Connect function varies depending on different speed dome models. 4. Click Activate to start activation. You can check whether the activation is completed on the popup window. If activation failed, make sure that the password meets the requirement and then try again. 5. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the Enable DHCP checkbox.
Figure 2-6 iVMS-4200 Control Panel 2. Click Device Management to enter the Device Management interface, as shown in Figure 2-7. Figure 2-7 Device Management Interface 3. 4. 5. Check the device status from the device list, and select an inactive device. Click Activate to pop up the Activation interface. Create a password and input the password in the password field, and confirm the password.
For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.
2.2 Setting the Network Camera over the WAN Purpose: This section explains how to connect the network camera to the WAN with a static IP or a dynamic IP. 2.2.1 Static IP Connection Before you start: Apply a static IP from an ISP (Internet Service Provider). With the static IP address, you can connect the network camera via a router or connect it to the WAN directly. Connecting the network camera via a router Steps: 1. Connect the network camera to the router. 2.
2.2.2 Dynamic IP Connection Before you start: Apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network camera to a modem or a router. Connecting the network camera via a router Steps: 1. Connect the network camera to the router. 2. In the camera, assign a LAN IP address, the subnet mask and the gateway. Refer to Section 2.1.2 for detailed LAN configuration. 3. In the router, set the PPPoE user name, password and confirm the password. 4. 5. 6. 7.
3. Visit the camera via the applied domain name.
13 User Manual of Network Speed Dome Chapter 3 Accessing to the Network Speed Dome 3.1 Accessing by Web Browsers Steps: 1. Open the web browser. 2. In the address field, input the IP address of the network camera, e.g., 192.168.1.64 and press the Enter key to enter the login interface. 3. Activate the camera for the first time using. Refer to the Section 2.1.2 Activating the Camera. 4. Select English as the interface language on the top-right of login interface. 5.
3.2 Accessing by Client Software The product CD contains the client software. You can view the live video and manage the camera with the client software. Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown in Figure 3-2.
Notes: If you use third party VMS software, contact our technical support for camera firmware. For detailed information about client software of our company, refer to the user manual of the software. This manual mainly introduces accessing to the network camera by web browser.
User Manual of Network Speed Dome 16 Chapter 4 Basic Operations In this and the following chapters, operation of the speed dome by the web browser will be taken as an example. 4.1 Power-up Action After power up, the speed dome will perform self-test action. It begins with lens action and then pan/tilt movement. After the self-test action, the system information of the speed dome including model, address, communication, version, and others will be displayed on screen for 40 seconds. 4.
Figure 4-1 Live View Parameters Record File Settings: Set the saving path of the video files. Record File Size: Select the packed size of manually recorded and downloaded video files. The size can be set to 256M, 512M or 1G. Save record files to: Set the saving path for the manually recorded video files. Save downloaded files to: Set the saving path for the downloaded video files in interface. Picture and Clip Settings: Set the saving paths of the captured pictures and clipped video files.
Menu Bar PTZ Control Show/hide PTZ control panel Live View Window Live View Parameters Toolbar Preset/Patrol/Pattern Figure 4-2 Live View Page Menu Bar: Click each tab to enter Live View, Playback, Picture, and Configuration page respectively. Click to display the help file of the network camera. Click to logout the system. Live View Window: Display the live video. Toolbar: Operations on the live view page, e.g.
Figure 4-3 Start Live View Table 4-1 Descriptions of the Toolbar and Live View Parameters Icon Description Click the button to enable Pixel Counter. Draw an area in live view window, and it shows the height and width of the selected area. Start/stop Live view. / Manually capture the pictures. / Manually start/stop recording. Steps: / 1. Click the button to enable Digital Zoom function. 2. Draw a rectangle on the image as the target area, and the area will be zoomed in. 3.
/ / / Click / to select from and display live video in 4:3/16:9/ original/original ratio/self-adaptive window size. Click to select from and display live video with the main/ sub/third stream. The main stream is with a relatively high / / resolution and needs more bandwidth. The default setting of stream type is . Click to select between Web Components or Quick Time.
Follow pop-up prompts to complete Internet Explorer 8+ plug-in installation to obtain high quality display and complete functions the camera offers. Plug-in installation is not required. Enable WebSocket or WebSockets (Configuration Others Google Chrome 57+ Mozilla Firefox 52+ Mac Safari 12+ Advanced > Network Settings > > Network Service) for normal live view. Display and operation of certain functions are restricted.
Figure 4-4 PTZ Control Panel Table 4-2 Descriptions of PTZ Control Panel Button Name Description Hold and press the directional button PTZ Control Panel to pan/tilt the camera. Click , then the camera keeps panning when the icon turns into . Click the icon again to stop the camera. Zoom out/in Click , then the lens zooms in. Click , then the lens zooms out.
Button Name Description Click Focus near/far , then the lens focuses far and the object far away gets clear. Click , then the lens focuses near and the object nearby gets clear. When the image is too dark, click Iris close/open to enlarge the iris. When the image is too bright, click to stop down the iris. Refer to Section 4.5.2 Auxiliary Auxiliary Functions Functions for detailed information of auxiliary functions Speed Adjustment Adjust speed of pan/tilt movements. Refer to Section 4.5.
4.5.2 Auxiliary Functions Note: These functions may differ from different cameras. Please take the actual product as standard. The Auxiliary functions panel is shown in Figure 4-5. Figure 4-5 Auxiliary Functions Table 4-4 Descriptions of Auxiliary Functions Button Name Description Light Click the button to enable/disable the light supplement of the camera. Wiper Click the button to move the wiper once. The function can only be realized with wiper device.
Click One-touch Patrol One-touch Park to call one-touch patrol. For detailed information of setting one-touch patrol, refer to Section 4.5.5 One-touch Patrol. Click to save the current view as the preset No. 32 and start park at the current position. Before you start: To use manual face capture, you should configure the function first. Configuration > Face Capture Steps: Face Capture 1. Click to start manual face capture. 2. Select the target face in PTZ camera channel by drawing a rectangle area.
4. Edit a preset name by double clicking on the default name such as preset 1. (The pre-defined presets are named already but not configurable. Refer to the user manual for detailed function description.) 5. You can click to delete the preset. Note: You can configure up to 272 presets. Calling a Preset: In the PTZ control panel, select a defined preset from the list and click to call the preset.
44 Call pattern 4 103 Call patrol 6 45 One-touch Patrol 104 Call patrol 7 46 Day/Night Auto Mode 105 Call patrol 8 Figure 4-8 Special Preset Note: You may need to use the OSD (On Screen Display) menu when controlling the camera remotely. To display the OSD menu on the live view screen, you can call the preset number 95. 4.5.4 Setting/Calling a Patrol Purpose: A patrol is a memorized series of preset function. It can be configured and called on the patrol settings interface.
Figure 4-9 Adding Presets 4. Configure the preset number, patrol time and patrol speed. Name Description Patrol Time It is the duration staying on one patrol point. The camera moves to another patrol point after the patrol time. Patrol Speed It is the speed of moving from one preset to another. 5. Click OK to save a preset into the patrol. 6. Repeat the steps from 3 to 5 to add more presets. 7. Click OK to save all the patrol settings.
No.32 to the patrol path 8. You can call the one-touch patrol and the camera moves as the patrol path 8 automatically. Steps: 1. Set preset No.1 to No.32. Refer to Section 4.5.3 Setting/Calling a Preset for detailed information of setting preset. 2. Call preset No. 45, and the camera moves as patrol path 8. 3. Click to enter the patrol settings interface and start/stop one-touch patrol, edit the patrol time and the speed. 4. You can click of the PTZ control panel to start one-touch patrol.
Figure 4-12 Patterns Settings Interface 3. Click to enable recording the panning, tilting and zooming actions. 4. Use the PTZ control buttons to move the lens to the desired position after the information of PROGRAM PATTERN REMAINNING MEMORY (%) is displayed on the screen. Pan the camera to the right or left. Tilt the camera up or down. Zoom in or out. Refocus the lens. 5. Click to save all the pattern settings.
2. Select a mode from the dropdown list: One time: Click on the preview interface, and the wiper sweeps once. Cycle: You need to set the working duration and interval of the wiper. Then click on the preview interface, and the wiper works continuously. Auto: The device turns on the wiper automatically when the sensor detects water droplets on the glass. Figure 4-13 Wiper Configuration 4.6 Playback Purpose: This section explains how to view the video files stored in the network disks or memory cards.
Figure 4-14 Playback Interface 2. Select the date and click . Figure 4-15 Search Video 3. Click to play the video files found on this date. The toolbar on the bottom of Playback interface can be used to control playing process.
Table 4-6 Description of the buttons Button Operation Button Operation Play Capture a picture Start/Stop clipping Pause / Stop video files / Volume up/down Speed down Download Speed up Playback by frame Enable/Disable / digital zoom Notes: You can choose the file paths locally for downloaded playback video files and pictures in Local Configuration interface. Refer to Section 4.2 Configuring Local Parameters for details.
Figure 4-20 Video Downloading interface 3. Check the checkbox in front of the video files that you need to download. 4. Click to download the video files. 4.7 Pictures Purpose: This section explains how to view the captured picture files stored in the network disks or the memory cards and download the captured pictures. Note: If you are using Google Chrome 57 and its above version or Mozilla Firefox 52 and its above version, plug-in installation is not compulsory.
Figure 4-21 Picture Interface 2. 3. 4. Select the file type. Set the start time and end time. Click Search. The corresponding picture files will be listed. Check the checkbox in front of the files that you need to download. 5. Click to download the files.
Chapter 5 System Configuration 5.1 Storage Settings Before you start: To configure record settings, make sure that you have the network storage device within the network or the memory card inserted in your camera. 5.1.1 Configuring Recording Schedule Purpose: There are two kinds of recording for the camera: manual recording and scheduled recording. In this section, you can follow the instructions to configure the scheduled recording.
Figure 5-2 Record Parameters Pre-record: The time you set to start recording before the scheduled time or the event. For example, if an alarm triggers recording at 10:00, and the pre-record time is set as 5 seconds, the camera starts to record at 9:59:55. The pre-record time can be configured as No Pre-record, 5 s, 10 s, 15 s, 20 s, 25 s, 30 s or not limited. Note: The pre-record time changes according to the video bitrate.
configuring the recording schedule, you have to configure the settings on the Motion Detection and Alarm Input settings interfaces. Record Triggered by Motion & Alarm: If you select Motion & Alarm, the video will be recorded when the motion and alarm are triggered at the same time. Besides configuring the recording schedule, you have to configure the settings on the Motion Detection and Alarm Input settings interfaces.
Figure 5-4 Segment Snapshot Settings 6. Click to enter the advanced setting interface. You can select the stream type of the capture. 7. Click to enter the Capture Parameters Interface. 8. Check the Enable Timing Snapshot checkbox to enable continuous snapshot, and configure the schedule of timing snapshot. Check the Enable Event-triggered Snapshot checkbox to enable event-triggered snapshot. 9. Select the format, resolution, quality of the snapshot. 10. Set the time interval between two snapshots.
The network disk should be available within the network and properly configured to store the recorded files, log files, etc. Steps: Add the network disk 1. Enter the NAS (Network-Attached Storage) settings interface: Configuration > Storage > Storage Management > Net HDD Figure 5-5 Select Net HDD Type 2. Enter the IP address and the file path of the network disk. 3. Select the mounting type. NFS and SMB/CIFS are selectable.
Figure 5-6 Storage Management Interface 2. If the status of the disk is Uninitialized, check the corresponding checkbox to select the disk and click Format to start initializing the disk. 3. When the initialization completed, the status of disk will become Normal as shown in Figure 5-7. Figure 5-7 View Disk Status Define the Quota for Record and Pictures 1. Input the quota percentage for picture and for record. 2. Click Save and refresh the browser page to activate the settings.
To initialize, refer to the steps of NAS disk initialization 5.1.4 Configuring Cloud Storage Figure 5-9 Cloud Storage configuration Steps: 1. Enter the Cloud Storage settings interface: Configuration > Storage > Storage Management > Cloud Storage 2. Check the checkbox to enable this function. 3. Select Protocol Version from dropdown list. 4. Enter the Server IP, Server Port, AccessKey, SecretKey, and Picture Storage Pool ID. 5. Click to save the settings. 5.
The functions vary depending on different camera models. 5.2.1 Configuring Motion Detection Purpose: Motion detection is a feature which can trigger alarm actions and actions of recording videos when the motion occurred in the surveillance region. Steps: 1. Enter the motion detection setting interface: Configuration > Event > Basic Event > Motion Detection 2. Check the checkbox of the Enable Motion Detection to enable this function.
(1) Click and drag the mouse on the live video image to draw a motion detection area. (2) Click to finish drawing. Note: You can click to clear all of the areas. (3) Move the slider to set the sensitivity of the detection. Expert Figure 5-11 Motion Detection Settings-Expert 4. Steps: (1) Set the Scheduled Image Settings, there are OFF, Auto-Switch and Scheduled-Switch selectable.
(1) Click tab to enter the arming schedule setting interface. Figure 5-12 Arming Schedule (2) Select the timeline of a certain day, and drag the mouse to set the arming schedule (the start time and end time of the arming task). (3) After you set the scheduled task, you can click (optional).
Figure 5-14 Segment Arming Settings (5) Click 5. to save the settings. Note: The time of each period cannot be overlapped. Up to 8 periods can be configured for each day. Set the Alarm Actions for Motion Detection. Click tab to enter the Linkage Method interface. You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method. Figure 5-15 Linkage Method Check the checkbox to select the linkage method.
Note: To send the Email when an event occurs, you need to refer to Section 6.1.2 Configuring Email Settings to set the Email parameters. Notify Surveillance Center Send an exception or alarm signal to remote management software when an event occurs. Upload to FTP/Memory/NAS Capture the image when an alarm is triggered and upload the picture to a FTP server. Note: You need a FTP server and set FTP parameters first. Refer to Section 6.1.2 Configuring FTP Settings for setting FTP parameters.
To trigger an alarm output when an event occurs, refer to Section 5.2.4 Configuring Alarm Output to set the alarm output parameters. Trigger Recording Record a video when an event occurs. Note: You have to set the recording schedule to realize this function. Refer to Section 5.1.1 Configuring Recording Schedule for settings the recording schedule. 5.2.2 Configuring Video Tampering Alarm Purpose: You can configure the camera to trigger the alarm actions when the lens is covered. Steps: 1.
6. Click tab to select the linkage method taken for tampering. Notify surveillance center, send email and trigger alarm output are selectable. Refer to Section 5.2.1 Configuring Motion Detection. 7. Click to save the settings. 5.2.3 Configuring Alarm Input Steps: 1. Enter the Alarm Input settings interface: Configuration > Event > Basic Event > Alarm Input 2. Choose the Alarm Input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed). 3.
7. You can copy your settings to other alarm inputs. 8. Click to save the settings. Figure 5-18 Linkage Method 5.2.4 Configuring Alarm Output Steps: 1. Enter the Alarm Output settings interface: Configuration> Event > Basic Event > Alarm Output 2. Select one alarm output channel in the Alarm Output dropdown list. 3. 4. 5. Set a name in for the alarm output (optional). The Delay time can be set to 1sec, 5sec, 10sec, 30sec, 1min, 2min, 5min, 10min or Manual.
Figure 5-19 Alarm Output Settings 6. You can copy the settings to other alarm outputs. 7. Click to save the settings. 5.2.5 Handling Exception The exception type can be HDD Full, HDD Error, Network Disconnected, IP Address Conflicted and Illegal Login. Steps: 1. Enter the Exception settings interface: Configuration > Event > Basic Event > Exception 2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Section 5.2.1 Configuring Motion Detection.
Figure 5-20 Exception Settings 3. Click to save the settings. 5.3 Smart Event Configuration Note: The functions vary depending on different camera models. Before Smart Event Configuration, you need to set VCA Resource as Smart Event: Configuration > System > System Settings > VCA Resource 5.3.1 Detecting Audio Exception Purpose: When you enable this function and audio exception occurs, the alarm actions will be triggered. Steps: 1.
Figure 5-21 Audio Exception Detection 2. 3. 4. 5. Check the checkbox of Audio Loss Detection to enable the audio input exception detection. Check the checkbox of Sudden Increase of Sound Intensity Detection checkbox to enable the sudden rise detection. Sensitivity: The smaller the value the more obvious sound change will trigger the detection. Sound Intensity Threshold: It can filter the sound in the environment, the louder the environment sound, the higher the value should be.
5.3.2 Configuring Face Detection Purpose: After the face detection is enabled, a face appears in the surveillance area, it will be detected and certain actions may be triggered by the detection. Steps: 1. Enter the face detection interface Configuration > Event > Smart Event > Face Detection 2. Check the Enable Face Detection checkbox. 3. You can check the Enable Dynamic Analysis for Face Detection checkbox if you want the detected face get marked with rectangle in the live view (optional).
Figure 5-23 Configuring Intrusion Area 3. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the intrusion detection interface. Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. 4. Select a region. 5. Draw area. 1) Select the Region No.in dropdown list. 2) Click to draw a rectangle on the image as a defense region.
For network cameras, regions can be set simultaneously before clicking Save button. For speed domes, you need to set 1 region and save it. Then continue to set and save the next region. 7. Click tab to enter the arming schedule setting interface. The time schedule configuration is the same as the settings of the arming schedule for motion detection. Refer to Section 5.2.1 Configuring Motion Detection for more details. 8.
Figure 5-24 Configuring Line 5. Draw area. 4) Click to draw a line on the image. 5) Click the line to switch to the editing mode. Drag an end to the desired place to adjust the length and angle of the line. And drag the line to adjust the location. 6. Configure the parameters for each defense region separately. Direction: Select the detection direction in the dropdown list, there are A<->B, A->B and B->A selectable.
8. Click tab to select the linkage method taken for the line crossing detection, Notify Surveillance Center, Send Email, Upload to FTP/Memory Card/NAS, Trigger Alarm Output, Trigger Recording, Smart Tracking, White Light Flashing, and Audible Warning are selectable. For speed dome, you can also choose to link smart tracking. Smart Tracking should be configured in advance. For certain models, White Light Flashing and Audible Warning are supported. Refer to Section 5.2.
3. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the line crossing detection interface. Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. 4. Select the region from the dropdown list for detection settings. 5. Click the button to start the region drawing. 6.
Figure 5-26 Configuring Region Exiting Detection 3. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the line crossing detection interface. Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. 4. Select the region from the dropdown list for detection settings. 5. Click the button to start the region drawing. 6.
For speed dome, you can also choose to link smart tracking. Smart Tracking should be configured in advance. For certain models, White Light Flashing and Audible Warning are supported. Refer to Section 5.2.1 Configuring Motion Detection for detailed configuration. 10. Click button to save the settings. 5.3.
6. 7. Click on the live video to specify the four vertexes of the detection region, and right click to complete drawing. Repeat the step to configure other regions. Up to 4 regions can be set. You can click the button to clear all pre-defined regions. Configure the parameters for each defense region separately. Threshold Level: If you set the value as 5, alarm is triggered immediately after the object entering the region.
Figure 5-28 Configuring Object Removal Detection Steps: 1. Enter the Object Removal Detection settings interface: Configuration> Event > Smart Event> Object Removal Detection 2. Check the checkbox of Enable to enable the Object Removal Detection function. 3. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the unattended baggage detection interface.
8. Click tab to enter the arming schedule setting interface. The time schedule configuration is the same as the settings of the arming schedule for motion detection. Refer to Section 5.2.1 Configuring Motion Detection for more details. 9. Click tab to select the linkage method taken for the object removal alarm, Notify Surveillance Center, Send Email, Upload to FTP, Trigger Channel, Smart Tracking and Trigger Alarm Output are selectable. Refer to Section 5.2.
Figure 5-29 Basic Settings 2. Configure the following settings: Basic Parameters: Set the basic parameters of PTZ. Proportional Pan: If you enable this function, the pan/tilt speeds change according to the amount of zoom. When there is a large amount of zoom, the pan/tilt speed will be slower for keeping the image from moving too fast on the live view image.
Keyboard Control Speed: Define the speed of PTZ control by a keyboard as Low, Medium or High. Auto Scan Speed: The scan speed can be set from level 1 to 40. Max. Tilt-angle: Set the tilt-angle of the speed dome from the dropdown list. Zooming Speed: The zoom speed is adjustable from level 1 to 3. PTZ OSD: Set the on-screen display duration of the PTZ status. Zoom Status: Set the OSD duration of zooming status as 2 seconds, 5 seconds, 10 seconds, NC (Normally Closed), or NO (Normally Open).
Figure 5-30 Configure the PTZ Limit 2. Click the Enable Limit checkbox and choose the limit type as manual stops or scan stops. Manual Stops: When manual limit stops are set, you can operate the PTZ control panel manually only in the limited surveillance area. Scan Stops: When scan limit stops are set, the random scan, frame scan, auto scan, tilt scan, panorama scan is performed only in the limited surveillance area. Note: Manual Stops of Limit Type is prior to Scan Stops.
1. Enter the Initial Position configuration interface: Configuration > PTZ > Initial Position Figure 5-31 PTZ Configuration 2. 3. 4. 5. Click the PTZ control buttons to find a position as the initial position of the speed dome; you can also call a defined preset and set it as the initial position of the speed dome. Click Set to save the position. Click Call, and the device moves to the set initial position. You can click Clear to delete the set initial position. 5.4.
Figure 5-32 Set the Park Action 2. 3. 4. 5. Check the Enable Park Action checkbox. Set the Park Time as the inactivity time of the camera before it starts the park actions. Choose Action Type from the dropdown list. If you select Patrol, Pattern, or Preset as Action Type, you need to select Action Type ID from the dropdown list. 6. Click to save the settings. 5.4.
6. Click to finish drawing or click to clear all of the areas you set without saving them. 7. Click to save the privacy mask, and it will be listed in the Privacy Mask List area. 8. Modify the mask settings. Type: you can specify a desired color for the mask or set it as mosaic. Note: The mosaic option may not be supported by certain camera models. Active Zoom Ratio: The set mask is only valid when the camera zoom ratio is equal to or larger than the set value.
2. 3. 4. 5. 6. Check the Enable Scheduled Task checkbox. Set the Park Time. You can set the park time (a period of inactivity) before the speed dome starts the scheduled tasks. Select the task type from the dropdown list. Select the timeline of a certain day, and drag the mouse to set the recording schedule (the start time and end time of the recording task). After you set the scheduled task, you can click and copy the task to other days (optional). Figure 5-36 Edit the Schedule and Task Type 7.
Figure 5-37 Clear Config 5. Click to clear the settings. 5.4.8 Configuring Smart Tracking Purpose: The speed dome tracks the moving objects automatically after you configure this function. Note: The VCA speed dome do not support this function. Steps: 1. Enter the Smart Tracking settings interface: Configuration > PTZ > Smart Tracking Figure 5-38 Configure Smart Tracking 2. Check the Enable Smart Tracking check box to enable smart tracking function. 3. Set Zoom Ratio for tracking.
actual zoom ratio dynamically according to the detected target size and the set value. Larger value means larger zoom ratio. Note: As long as you set the Tracking Zoom Ratio value not as 0, the zoom ratio you set manually is invalid. 4. Set Duration. The speed dome stops tracking when the duration time is up. 5. Set Color Consistency.
Figure 5-40 Position Settings 2. Manually find the north position for the speed dome in Live View interface, and click Set at North to set the north direction. 3. After the speed dome changes its direction, you can click Point to North and the speed dome turns back to the north direction. 4. You can manually set GPS information of certain camera including Longitude and Latitude. 5. Click to save the settings. 5.4.
Figure 5-41 Rapid Focus 2. Check Enable to enable the function. 3. Calibrate the camera. (1) Add scenes for calibration. a. Adjust the camera to a desired scene via PTZ control buttons. b. Click Add to add the scene, and input Rate and Calibration Point Amount of the scene. c. Repeat above steps to add other scenes. (2) Adjust calibration line. a. Select an added scene, and a red line appears on live image. b. Adjust the length and position of the line by dragging its two endpoints.
5.5 Face Capture Configuration Notes: 11. When adjusting image and video effect, you can click to capture a image and click to record a video clip for testing. Pictures and videos are saved in your local computer. 12. Face capture function detects and captures faces in surveillance scenes. When the grading of the detected face exceeds an algorithm-defined value, the PTZ camera channel captures the face and triggers linkage actions.
target if in a live view or playback. Display on Picture: Check the checkbox, then there will be a frame on the target on the uploaded alarm picture if the checkbox is checked. Snapshot Settings: You can set the quality and resolution for the captured picture. Target Picture Settings: You can set the face picture type by selecting Custom, Head Shot, Half-Body Shot, or Full-Body Shot. If you select Custom, you can define detailed picture width and height of a picture freely.
Normal Mode Settings Steps: 1. Click to set up face capture rule. Figure 5-44 Area Settings 2. (Optional) Click Lock to lock PTZ to prevent the interruption from other PTZ related action during configuration. Normally, the PTZ control is automatically locked when you enter the configuration interface. You can manually resume the lock when the countdown is over. 3. Use PTZ control panel or click 4. Click to locate a scene with a face. and draw detection area on live image. 5.
Expert Mode Settings 1. Click to set up face capture rule. 2. (Optional) Click Lock to lock PTZ to prevent the interruption from other PTZ related action during configuration. Normally, the PTZ control is automatically locked when you enter the configuration interface. You can manually resume the lock when the countdown is over. 3. Set detection scenes and detection areas. i. Select a Detection Scene from the dropdown list. ii. Adjust the live image to a desired scene.
Figure 5-45 Advanced Face Capture Parameters Following parameters can be configured on this interface: Generation Speed: The speed to identify a target can be set by adjusting the slider, ranging from 1 to 5. The higher the value is, the faster the target will be recognized. The default value is recommended. Sensitivity: The sensitivity to identify a target can be set by adjusting the slider, ranging from 1 to 5.
in the configured area. Face Exposure: Check the checkbox to enable the Face Exposure. The device automatically adjusts exposure level when human faces appear in the scene. Reference Brightness: The reference brightness of a face in the face exposure mode. If a face in the actual scene is brighter than the set reference brightness, the device lower the exposure level. If a face in the actual scene is darker than the set reference, the device increases the exposure level.
Chapter 6 Camera Configuration 6.1 Configuring Network Settings Note: The functions vary depending on different camera models. 6.1.1 Basic Settings Configuring TCP/IP Settings Purpose: TCP/IP settings must be properly configured before you operate the camera over network. IPv4 and IPv6 are both supported. Steps: 1. Enter TCP/IP settings interface: Configuration > Network > Basic Settings > TCP/IP Figure 6-1 TCP/IP Settings 2.
You can click Test to make sure that the IP address is valid. Notes: If the DHCP server is available, you can check to automatically obtain an IP address and other network settings from that server. The valid value range of Maximum Transmission Unit (MTU) is 1280 to 1500. The Multicast sends a stream to the multicast group address and allows multiple clients to acquire the stream at the same time by requesting a copy from the multicast group address.
(2) In the Domain text field, enter the domain name obtained from the DynDNS website. (3) Enter the Port of DynDNS server. (4) Enter the User Name and Password registered on the DynDNS website. (5) Click to save the settings. Figure 6-3 DynDNS Settings NO-IP: Steps: (1) Enter Server Address of NO-IP. (2) In the Domain text field, enter the domain name obtained from the NO-IP website. (3) Enter the Port of NO-IP server. (4) Enter the User Name and Password registered on the NO-IP website.
For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.
WebSockets Port: The default server port number is 7682. Note: WebSocket and WebSockets protocol are used for plug-in free live view. For detailed information, see Network Service in Section 6.1.2.Network Service. 3. Click to save the settings. Configuring NAT (Network Address Translation) Settings Purpose: Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among networking equipment, software and other hardware devices.
6.1.2 Advanced Settings Configuring SNMP Settings Purpose: You can use SNMP to get camera status and parameters related information. Before you start: Before setting the SNMP, use the SNMP software and manage to receive the camera information via SNMP port. By setting the Trap Address, the camera can send the alarm event and exception messages to the surveillance center. Note: The SNMP version you select should be the same as that of the SNMP software. Steps: 1.
SNMP v3) to enable the feature. 3. Configure the SNMP settings. Note: The configuration of the SNMP software should be the same as the settings you configure here. 4. Click to save and finish the settings Configuring FTP Settings Purpose: You can set a FTP server and configure the following parameters for uploading captured pictures. Steps: 1. Enter the FTP settings interface: Configuration > Network > Advanced Settings > FTP Figure 6-8 FTP Settings 2.
In the Directory Structure field, you can select the root directory, parent directory and child directory. Root directory: The files will be saved in the root of FTP server. Parent directory: The files will be saved in a folder in FTP server. The name of folder can be defined as shown in Figure 6-9. Figure 6-9 Parent Directory Child directory: It is a sub-folder which can be created in the parent directory. The files will be saved in a sub-folder in FTP server.
Figure 6-11 Email Settings 2. Configure the following settings: Sender: The name of the email sender. Sender’s Address: The email address of the sender. SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com). SMTP Port: The SMTP port. The default TCP/IP port for SMTP is 25. E-mail encryption: None, SSL, and TLS are selectable. When you select SSL or TLS and disable STARTTLS, e-mails will be sent after encrypted by SSL or TLS.
Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Receiver: Select the receiver to which the email is sent. Up to 2 receivers can be configured. Receiver: The name of the user to be notified. Receiver’s Address: The email address of user to be notified. (Optional: click Test to make sure that the email server can send email out.) 3. Click to save the settings.
Note: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Configuring HTTPS Settings Purpose: HTTPS consists of SSL&HTTP. It is used for encryption transmission, identity authentication network protocol which enhances the security of WEB accessing. For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices.
Figure 6-14 Create Self-signed Certificate (3) Enter the country, host name/IP, validity and other information. (4) Click OK to save the settings. OPTION 2: Start the installation when signed certificate is available. (1) Select Signed certificate is available, Start the installation directly. (2) Click Browse to upload the available certificate. (3) Click Install button to install the certificate. (4) Click OK to save the settings. OPTION 3: Create certificate request first and continue the installation.
address:port number, eg., https://192.168.1.64:81. Configuring QoS Settings Purpose: QoS (Quality of Service) can help solve the network delay and network congestion by configuring the priority of data sending. Steps: 1. Enter the QoS settings interface: Configuration > Network > Advanced Configuration > QoS Figure 6-16 QoS Settings 2. Configure the QoS settings, including Video/Audio DSCP, Event/Alarm DSCP and Management DSCP. The valid DSCP value ranges from 0 to 63.
Authenticator Network Switch Network Speed Dome Internet Authentication Server PC PC RADIUS Server Figure 6-17 Protected LAN Before connecting the Network Camera to the protected LAN, apply a digital certificate from a Certificate Authority. The network camera requests access to the protected LAN via the authenticator (a switch). The switch forwards the identity and password to the authentication server (RADIUS server).
3. 4. 6. Check the Enable IEEE 802.1x checkbox to enable it. Select a preferred protocol. EAP-LEAP, EAP-TLS, and EAP-MD5 are selectable. EAP-LEAP and EAP-MD5 If you use EAP-LEAP or EAP-MD5, the authentication server must be configured. Apply and register a user name and password for 802.1X in the server. Input the user name and password to access the server. EAP-TLS If you use EAP-TLS, input Identify, Private Key Password, and upload CA Certificate, User Certificate and Private Key.
Figure 6-19 Integration Protocol Settings 2. Check the Enable Hikvision-CGI checkbox and then select the authentication from the dropdown list. Then you can access to the camera through the third party platform. 3. Check the Enable ONVIF checkbox to enable the function. 4. Click Add to add a new ONVIF user. Set the user name and password, and confirm the password. You can set the user as media user, operator, and administrator. 5. Click Modify to modify the information of the added ONVIF user. 6.
3. Save the settings. Figure 6-20 HTTP Listening TCP Acceleration Purpose: TCP acceleration is used to improve latency and reduce packet loss caused by network congestion in poor network condition, and guarantee the fluency of live view. Steps: 1. Enter the TCP Acceleration interface. Configuration > Network > Advanced Settings > TCP Acceleration 2. Check to enable the function. 3. Save the settings.
Figure 6-22 Traffic Shaping 6.2 Configuring Video and Audio Settings 6.2.1 Configuring Video Settings Steps: 1. Enter the Video settings interface: Configuration > Video/Audio > Video Figure 6-23 Configure Video Settings 2. Select the Stream Type of the camera to Main Stream (Normal), Sub-stream or Third Stream. The main stream is usually for recording and live viewing with good bandwidth, and the sub-stream can be used for live viewing when the bandwidth is limited. Refer to the Section 4.
The parameters vary depending on different camera models. Video Type: Select the stream type to video stream, or video & audio composite stream. The audio signal will be recorded only when the Video Type is Video & Audio. Resolution: Select the resolution of the video output. Bitrate Type: Select the bitrate type to constant or variable. Video Quality: When bitrate type is selected as Variable, 6 levels of video quality are selectable.
Smoothing: It refers to the smoothness of the stream. The higher value of the smoothing, the better fluency of the stream, though, the video quality may not be so satisfied. The lower value of the smoothing, the higher quality of the stream, though it may appear not fluent. 4. Click to save the settings. 6.2.2 Configuring Audio Settings Steps: 1. Enter the Audio settings interface Configuration > Video/Audio > Audio Figure 6-24 Audio Settings 2. Configure the following settings. Audio Encoding: G.
Audio Output, LineOut, and Output Volume are only supported on certain cameras. Environmental Noise Filter: Select ON or OFF in the dropdown list to enable or disable the function. It’s recommended to enable the function when sampling rate is lower than 32 kHz. 3. Click to save the settings. 6.2.3 Configuring ROI Settings Purpose: ROI (Region of Interest) encoding is used to enhance the quality of images which are specified in advance. There are two different ROI methods: Fixed Region and Dynamic Region.
Figure 6-26 Region of Interest (2) ROI for Fixed Region Steps: 1. Check Enable checkbox to enable the Fixed Region function. 2. Select a stream type. You can set the ROI function for Main Stream(Normal), Sub-stream or Third Stream. 3. Click can click and then drag the mouse to draw a red frame in the live view image. You to clear it. Note: The number of areas supported in ROI function varies depending different camera models 4. Select the Region No. from the dropdown list. 5. Adjust the ROI level.
including line crossing, intrusion, etc. 6.3 Configuring Image Settings On the Image configuration page, click to show the PTZ control panel or click it. Click the direction buttons to control the pan/tilt movements. Click the zoom/iris/focus buttons to realize lens control. The functions vary depending on different camera models. to hide 6.3.
You can limit the changing ranges of iris and shutter in Auto mode for better exposure effect. Iris Priority: The value of iris needs to be adjusted manually. The shutter and gain values will be adjusted automatically according to the brightness of the environment. You can limit the changing range of shutter in Iris Priority mode for better exposure effect. Figure 6-27 Manual Iris Shutter Priority: The value of shutter needs to be adjusted manually.
Slow Shutter This function can be used in underexposure condition. It lengthens the shutter time to ensure full exposure. Slow Shutter Level When slow shutter is set as ON, you can select the slow shutter level from the dropdown list. The slow shutter lever can be set to Slow Shutter*1.25, *1.5, *2, *3, *4, *6, *8. Figure 6-30 Slow Shutter Focus Settings Focus Mode The Focus Mode can be set to Auto, Manual, and Semi-auto.
In Night mode, the image is black and white. Night mode can increase the sensitivity in low light conditions. Scheduled-Switch: In Scheduled-Switch mode, you can set the start and end time for day mode as shown in Figure 6-32. The rest is the time for night mode. Figure 6-32 Day Night Schedule Supplement Light Smart Supplement Light: It controls the power of light automatically to make image of proper exposure level.
White Balance The White Balance mode can be set to Auto, MWB, Outdoor, Indoor, Fluorescent Lamp, Sodium Lamp, and ATW. Auto In Auto mode, the camera retains color balance automatically according to the current color temperature. Manual White Balance: In MWB mode, you can adjust the color temperature manually to meet your own demand as shown in Figure 6-34. Figure 6-34 Manual White Balance Outdoor You can select this mode when the speed dome is installed in outdoor environment.
Figure 6-36 Expert Mode Defog Mode You can set the Defog Mode to Auto, ON or OFF as you need. Figure 6-37 Defog Mode EIS (Electronic Image Stabilization) You can set the EIS to ON or OFF as you need. Figure 6-38 Electronic Image Stabilization OIS (Optical Image Stabilization) You can set the OIS to NORMAL, EXPERT, or OFF as you need. Note: The function is only available for certain camera models.
from the list. Local Output You can select the output mode to ON or OFF. Note: The functions vary depending on different camera models. 6.3.2 Configuring OSD Settings Purpose: OSD (On-screen Display) refers to the camera name, time/date, customized information displayed on the live view. Note: This function varies according to different camera models. Steps: 1. Enter the OSD settings interface: Configuration > Image > OSD Settings 2. Select Character Set.
Figure 6-40 Adjust OSD Location 7. Click to activate above settings. Configuring Text Overlay Settings Purpose: You can customize the text overlay. Steps: 1. Enter the Text Overlay settings interface: Configuration > Image > OSD Settings 2. Check the checkbox in front of textbox to enable the on-screen display. 3. Input the characters in the textbox. 4. Use the mouse to drag the red text frame Text in the live view window to adjust the text overlay position. 5. Click to save the settings. 6.3.
Figure 6-42 Linked Scene 4. When you enable the function of Scheduled-Switch, check the corresponding checkbox, set the time period and the linked scene. Figure 6-43 Schedule-Switch 5. Click to save the settings. Note: The two functions are not enabled by default. 6.4 Configuring System Settings 6.4.
Figure 6-44 Device Information Time Settings Purpose: You can follow the instructions in this section to configure the time which can be displayed on the video. There are Time Zone, Time Synchronization, and Daylight Saving Time (DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol (NTP) server and manual mode.
NTP Port: Port of NTP server. Interval: The time interval between the two synchronizing actions by NTP server. It can be set from 1 to 10080 minutes. Figure 6-46 Time Sync by NTP Server You can click to make sure that the NTP server is connected. Note: If the camera is connected to a public network, you should use a NTP server that has a time synchronization function, such as the server at the National Time Center (IP Address: 210.72.145.44).
From the Time Zone dropdown menu as shown in Figure 6-48, select the Time Zone in which the camera locates. Figure 6-48 Time Zone Settings Configuring DST (Daylight Saving Time) Purpose: Daylight Saving Time (DST) is a way of making better use of the natural daylight by setting your clock forward one hour during the summer months, and back again in the fall. If there is the habit of adjusting clocks forward in your country in certain time period of a year, you can turn this function on.
Figure 6-50 RS-232 Settings 2. Configure the Baud Rate, Data Bit, Stop Bit, Parity, Flow Control, and Usage. Note: If you want to connect the camera through RS-232 port, the parameters of the RS-232 should be exactly the same with the parameters you configured here. 3. Click to save the settings. RS-485 Purpose: The RS-485 serial port is used to control the PTZ of the camera. The configuring of the PTZ parameters should be done before you control the PTZ unit.
VCA Resource Purpose: VCA Resource offers options to enable certain VCA functions and hide others. It helps allocate more resources to the wanted functions. A reboot is required after setting the VCA Resource. Steps: 1. Enter the VCA Resource interface: Configuration> System > System Settings > VCA Resource 2. Select a desired VCA combination. 3. Click to save the settings. A reboot is needed for the settings to take effect. Notes: VCA Resource function varies according to different camera models.
Figure 6-52 Restore Default Settings Exporting Configuration File Steps: 1. Enter the Maintenance interface: Configuration > System > Maintenance > Upgrade & Maintenance 2. Click Device Parameters and set the encryption password to export the current configuration file. 3. Set the saving path to save the configuration file in local storage. 4. Click Diagnose Information to download the log and system information. Importing Configuration File Steps: 1.
Steps: 1. Enter the Log interface: Configuration > System > Maintenance > Log Figure 6-53 Log Searching Interface 2. Set the log search conditions to specify the search, including the Major Type, Minor Type, Start Time and End Time as shown in Figure 6-53. 3. Click to search log files. The matched log files will be displayed on the Log interface. 4. To export the log files, click Save Log to save the log files in your computer. System Service Steps: 1.
Security Audit Log Purpose: The Security Audit Log refers to the security operation logs. You can search and analyze the security log files of the camera so that to find out the illegal intrusion and troubleshooting the security events. Security audit logs can be saved on device flash. The log will be saved every half hour after device booting. Due to limited saving space of the flash, you can also save the logs on a log server. Configure the server settings at Advanced Settings.
information in the popup window. (2) Click Download to download the certificate request and submit it to the trusted certificate authority for signature. (3) Install the signed certificate to the device. CA Certificate You can install the CA certificate to the device. 6.4.3 Security Configuring Authentication Security Purpose: You can specifically secure the stream data of live view. Steps: 1. Enter the Authentication interface: Configuration> System> Security > Authentication 2.
Figure 6-56 IP Address Filter 2. Check the checkbox of Enable IP Address Filter. 3. Select the type of IP Address Filter in the dropdown list, Forbidden and Allowed are selectable. 4. Set the IP Address Filter list. Add an IP Address Steps: (1) Click Add to add an IP. (2) Input the IP Adreess. Figure 6-57 Add an IP (3) Click OK to finish adding. Modify an IP Address Steps: (1) Click an IP address from filter list and click Modify. (2) Modify the IP address in the text filed.
after the user performing certain failed password attempts. The number of allowed attempts is configurable. 3. Click to save the settings. Configuring Advanced Security Purpose: Advanced security offers options to manage more network security settings of the device. Security Reinforce Security reinforce is a solution to enhance network security.
permission to different user levels. We highly recommend administrator to manage the device accounts and user permissions properly. Up to 31 user accounts can be created. Figure 6-59 User Information Add a User Steps: 1. Click 2. Input the new User Name, select Level and input Password. to add a user. For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices.
Figure 6-60 Add a User Modify a User Steps: 1. Click to select the user from the list and click . 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification.
Figure 6-61 Modify a User Delete a User Steps: 1. Click the user name you want to delete and click 2. Click . on the pop-up dialogue box to delete the user. Recover Admin Password Purpose: The camera allows admin password recovery via security question. Recovery password operation is only available to administrator. Setup Security Question for Verification Code Steps 1. Click Account Security Settings to enter setting interface.
Steps: 1. Enter login interface via web browser. 2. Click Forget Password. 3. Follow pop-up message to complete operation. Online Users Enter the Online Users configuration interface: Configuration > System > User Management > Online Users Figure 6-62 Online Users You can see the current users who are visiting the device through this interface. User information, such as user name, level, IP address, and operation time, is displayed in the User List. Click Refresh to refresh the list.
Appendix SADP Software Introduction Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices. You can also modify the basic network information of the devices using this software.
click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. Modify network parameters Steps: 1. Select the device to be modified in the device list and the network parameters of the device will be displayed in the Modify Network Parameters panel on the right side. 2. Edit the modifiable network parameters, e.g. IP address and port number. 3.
Device Communication Matrix Scan the following QR code to get device communication matrix. Note that the matrix contains all communication ports of Hikvision network cameras. Device Command Scan the following QR code to get device common serial port commands. Note that the command list contains the commonly used serial port commands for all Hikvision network cameras.
UD16002B
