Data Sheet

Power Consumption and Current
-IZS: With extra load: 12 VDC, 1.28 A, max. 15.4 W; PoE (802.3at, 42.5 V to 57 V), 0.36
A to 0.27 A, max. 15.4 W; Without extra load: 12 VDC, 1.08 A, max. 13 W; PoE
(802.3at, 42.5 V to 57 V), 0.31 A to 0.23 A, max. 13 W
-IZHS: With extra load: 12 VDC, 1.33 A, max. 15.9 W; PoE (802.3at, 42.5 V to 57 V), 0.50
A to 0.37 A, max. 21.2 W; Without extra load: 12 VDC, 1.13 A, max. 13.5 W; PoE
(802.3at, 42.5 V to 57 V), 0.42 A to 0.32 A, max. 18 W
"With extra load" means that an extra device is connected to and powered by the
camera.
Heater
-H: yes
Material
Metal
Dimensions
Camera: Φ144 × 347 mm (Φ5.7ʺ × 13.7ʺ)
With package: 405 × 190 × 180 mm (15.9ʺ × 7.5ʺ × 7.1ʺ)
Weight
Camera: approx. 1.85 kg (4.07 lb.)
With package: approx. 2.95 kg (6.50 lb.)
Approval
EMC
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013,
EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32:
2015, KN 35: 2015
Safety
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am
1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry
2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
Protection
Ingress protection: IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
* Listed resolutions are only selectable options. It does not mean that all streams can work at their maximum resolution at the
same time.
Available Model
DS-2CD5A46G1-IZS (2.8 to 12 mm), DS-2CD5A46G1-IZHS (2.8 to 12 mm), DS-2CD5A46G1-IZS (8 to 32 mm),
DS-2CD5A46G1-IZHS (8 to 32 mm)
