Network Dome Camera·Quick Operation Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual applies to the following models. Model Model DS-2CD4112F-(I) DS-2CD4124F-(I) DS-2CD4132F-(I) DS-2CD4112FWD-(I) DS-2CD4132FWD-(I) iDS-2CD6124FWD-I/B This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
Network Dome Camera·Quick Operation Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Network Dome Camera·Quick Operation Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
Network Dome Camera·Quick Operation Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings Follow these safeguards to prevent serious injury or death.
Network Dome Camera·Quick Operation Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
Network Dome Camera·Quick Operation Guide ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30℃~+60℃,or -40°C ~ 60°C if the camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation. ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use.
Network Dome Camera·Quick Operation Guide Table of Contents 1 Appearance Description ................................................................. 8 2 Installation .................................................................................... 11 3 Setting the Network Camera over the LAN .................................. 18 4 Accessing via Web Browser ..........................................................
Network Dome Camera·Quick Operation Guide 1 Appearance Description The overview of the dome camera is shown below: Figure 1-1 Overview (1) The overview of the components and the interface are shown below: 2 3 4 56 7 8 Figure 1-2 Overview (2) The interfaces on the rear panel are shown below: 8
Network Dome Camera·Quick Operation Guide 9 10 Figure 1-3 Overview (3) Figure 1-4 Overview (4) 9
Network Dome Camera·Quick Operation Guide Table 1-1 Description of Overview (2~3) No. Description No. Description 1 Black Liner 2 Bubble 3 Lens 4 BNC Interface 5 Reset 6 Status Indicator 7 Test Serial Port 8 Micro SD Card Slot 9 Adapter Plate 10 Side Outlet Table 1-2 Description of Overview (4) No.
Network Dome Camera·Quick Operation Guide 2 Installation Before you start: Make sure the device in the package is in good condition and all the assembly parts are included. Make sure all the related equipment is power-off during the installation. Check the specification of the products for the installation environment. Make sure the power supply is matched with your required voltage to avoid damage.
Network Dome Camera·Quick Operation Guide ● Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera may reflect back into the lens causing reflection. ● The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS. Fasten the dome cover to camera body so that the foam ring and the dome cover are attached seamlessly. Steps: 1.
Network Dome Camera·Quick Operation Guide Side Outlet Figure 2-2 Side Outlet 2. Fix the adapter plate to the ceiling with the supplied screws.
Network Dome Camera·Quick Operation Guide 3. Align the mounting base with the adapter plate and route the mounting base anticlockwise to get it fitted with the adapter plate, and then fix it by tightening the lock screw. Lock Screw Figure 2-4 Install the Mounting Base 4. Adjust the surveillance angle according to the figure below. Panning angle [0~80°], tilting angle [0~355°], and azimuth angle of the lens [0~355°].
Network Dome Camera·Quick Operation Guide 5. Adjust the focus and zoom. 1). Connect the VIDEO OUT interface of the camera to the debugging monitor. 2). Set the iris type to MANUAL first. 3). Adjust the No.1 Zoom Lever (T~W) to select a proper angle of view. 4). Adjust the NO.2 Focus Lever (F~N) to obtain a perfect image on the monitor. 5).
Network Dome Camera·Quick Operation Guide Figure 2-7 Zoom and Focus Adjustment of Electronic Lens 6. Attach the black liner to the dome drive. 7. Attach the bubble to the dome drive and rotate it to get tightened. Dome Drive Bubble Black Liner Figure 2-8 Install the Black Liner and Bubble 8. Tighten the lock screw to complete the installation.
Network Dome Camera·Quick Operation Guide Figure 2-9 Complete the Installation 17
Network Dome Camera·Quick Operation Guide 3 Setting the Network Camera over the LAN Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or PCNVR software to search and change the IP of network camera. The following figure shows the cable connection of network camera and PC: Figure 3-1 Wiring over LAN Set the IP address of the camera for accessing via LAN. Steps: 1.
Network Dome Camera·Quick Operation Guide Use PCNVR software and to list the online devices. Please refer to the user manual of PCNVR client software for detailed information. 2. Change the IP address and subnet mask to the same subnet as of your PC.
Network Dome Camera·Quick Operation Guide Figure 3-2 Search Online Devices Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline.
Network Dome Camera·Quick Operation Guide You can also click to refresh the online device list manually. The newly searched devices will be added to the list. You can click or on each column heading to order the information; you can click to show the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. Modify device information Steps: 1). Select the device to be modified in the device list as shown in Figure 3-3.
Network Dome Camera·Quick Operation Guide Figure 3-3 Select a Device Figure 3-4 Modify Network Parameters 3. Enter the IP address of network camera in the address field of the web browser to view the live video.
Network Dome Camera·Quick Operation Guide The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”. For accessing the network camera from different subnets, please set the gateway for the network camera after you log in.
Network Dome Camera·Quick Operation Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version Steps: 1. Open the web browser. 2.
Network Dome Camera·Quick Operation Guide Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
Network Dome Camera·Quick Operation Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in (1) 26
Network Dome Camera·Quick Operation Guide Figure 4-4 Install Plug-in (2) 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.
