DS-2CD2746G2-IZS

4 MP AcuSense Powered-by-DarkFighter Motorized Varifocal Dome Network Camera

Empowered by deep learning algorithms, Hikvision AcuSense

technology brings human and vehicle targets classification

alarms to front- and back-end devices. The system focuses

on human and vehicle targets, vastly improving alarm

efficiency and effectiveness.



High quality imaging with 4 MP resolution



Excellent low-light performance with

powered-by-DarkFighter technology



Motorized varifocal lens for easy installation and

monitoring



Clear imaging against strong backlight due to 120 dB true

WDR technology



Efficient H.265+ compression technology



Focus on human and vehicle targets classification based on

deep learning



Audio and alarm interface available



Water and dust resistant (IP66) and vandal-resistant (IK10)

Summary of content (6 pages)

PAGE 1
DS-2CD2746G2-IZS 4 MP AcuSense Powered-by-DarkFighter Motorized Varifocal Dome Network Camera Empowered by deep learning algorithms, Hikvision AcuSense  High quality imaging with 4 MP resolution technology brings human and vehicle targets classification  Excellent low-light performance with alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm powered-by-DarkFighter technology  efficiency and effectiveness.
PAGE 2
 Specification Camera Image Sensor 1/3" Progressive Scan CMOS Min. Illumination Color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR Shutter Speed 1/3 s to 1/100,000 s Day & Night IR cut filter Slow Shutter Yes Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° P/N P/N Wide Dynamic Range 120 dB Power-off Memory Yes Lens Lens Type Focal Length & FOV Varifocal lens, motor-driven lens, 2.8 to 12 mm 2.
PAGE 3
Bit Rate Control CBR/VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 1 fixed region for main stream and sub-stream Audio Environment Noise Filtering Yes Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.
PAGE 4
Smart Event Scene change detection Deep Learning Function Face Capture Perimeter Protection Yes Line crossing detection, intrusion detection, region entrance detection, region exiting detection General Storage Conditions Startup and Operating Conditions Power Supply Power Consumption and Current -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) 12 VDC ± 25% PoE: 802.3af, Class 3 12 VDC, 0.88 A, max. 10.
PAGE 5
 Available Model DS-2CD2746G2-IZS (2.
