 Only the IR speed domes support IR Light Mode.
 When the IR Light Mode is auto, the day/night mode is adjusted automatically
according to the IR Light Mode. Manually setting the day/night mode is invalid.
 When the IR Light Mode is manual and the IR Light Bright is 0, you can set the
day/night mode manually.
 When the IR Light Mode is manual and the IR Light Bright is not 0, the night
mode is set as the default mode. Manually setting the day/night mode is invalid.
Backlight Settings
 BLC
If there’s a bright backlight, the subject in front of the backlight appears silhouetted
or dark. Enabling BLC(back light compensation) function can correct the exposure of
the subject. But the backlight environment is washed out to white.
 WDR (Wide Dynamic Range)
The wide dynamic range (WDR) function helps the camera provide clear images even
under back light circumstances. When there are both very bright and very dark areas
simultaneously in the field of view, WDR balances the brightness level of the whole
image and provide clear images with details.
You can enable or disable the WDR function as shown in Figure 6-33. The wide
dynamic level ranges from 0 to 100.
Figure 6-33 WDR
This function varies depending on the models of speed dome.
 HLC
HLC (High Light Compensation) makes the camera identify and suppress the strong
light sources that usually flare across a scene. This makes it possible to see the detail
of the image that would normally be hidden.
White Balance
The White Balance mode can be set to Auto, MWB, Outdoor, Indoor, Fluorescent
Lamp, Sodium Lamp and Auto-Track.
 Auto:
In Auto mode, the camera retains color balance automatically according to the
current color temperature.
 Manual White Balance:
In MWB mode, you can adjust the color temperature manually to meet your own
