 Buttons on the Patterns interface:
Buttons
Description
Start to record a pattern.
Stop recording a pattern.
Call the current pattern.
Stop the current pattern.
Delete the current pattern.
 These 4 patterns can be operated separately and with no priority level.
 When configuring and calling the pattern, proportional pan is valid; the limit stops and
auto flip will be invalid; and the 3D positioning operation is not supported.
4.5 Configuring Live View Parameters
 Main stream/Sub-stream:
You can select or as the stream type of live viewing.
The main stream is with a relatively high resolution and needs much bandwidth. The
sub-stream is with a low resolution and needs less bandwidth. The default setting of
stream type is .
Please refer to Section 6.4.1 Configuring Video Settings for more detailed
parameter settings of the main stream and sub-stream respectively.
 Image Size:
You can scale up/down the live view image by clicking . the
image size can be 4:3, 16:9, original or auto.
