User manual

User Manual of Network Speed Dome
© Hikvision
27
Figure 4-7 Adding Presets
4. Configure the preset number, patrol time and patrol speed.
Name
Description
Patrol Time
It is the duration staying on one patrol point. The speed
dome moves to another patrol point after the patrol time.
Patrol Speed
It is the speed of moving from one preset to another.
5. Click to save a preset into the patrol.
6. Repeat the steps from 3 to 5 to add more presets.
7. Click to save all the patrol settings.
 Calling a Patrol:
In the PTZ control panel, select a defined patrol from and click
to call the patrol as shown in Figure 4-8.
Figure 4-8 Calling a Preset
