Instruction manual

Network Dome Camera·Quick Operation Guide
10
10
Description of Overview (2~3) Table 1-1
No.
Description
No.
Description
1
Black Liner
2
Bubble
3
Lens
4
BNC Interface
5
Reset
6
Status Indicator
7
Test Serial Port
8
Micro SD Card Slot
9
Adapter Plate
10
Side Outlet
Description of Overview (4) Table 1-2
No.
Description
LAN（PoE）
10M/100M Self-adaptive Ethernet Port(PoE
Supported)
AUDIO OUT/IN：
Audio Out/In
CVBS，GND
Auxiliary video output
1A，1B
Alarm Out
D+，D-
RS-485 Interface
IN，GND
Alarm In
DC12V
Power Supply Interface（12 VDC ）
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.
