Network Box Camera·Quick Operation Guide
10
10
No.
Description
No.
Description
5
Auto-iris Interface
6
LAN(PoE)
7
Power Outlet
8
Reset
9
Micro SD Card Slot
10
Video Out
11
Grounding
12
Alarm Out
13
RS-232
14
RS-485
15
Alarm In
16
Audio Out
17
ABF
18
Audio In
 Only the models with “A” in its suffix support ABF function.
 To reset the camera default parameters, you need to press and
hold the RESET button and power on the camera. After the
power on of the camera, you must still press and hold the Reset
button for about 20 seconds.
 The type of auto-iris interface is shown as below figure:
Auto-iris Interface Figure 1-4
