Network Box Camera·Quick Operation Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual applies to the following camera models.
Network Box Camera·Quick Operation Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Network Box Camera·Quick Operation Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
Network Box Camera·Quick Operation Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings Follow these safeguards to prevent serious injury or death.
Network Box Camera·Quick Operation Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
Network Box Camera·Quick Operation Guide ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30℃~+60℃,or -40°C ~ 60°C if the camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation. ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use.
Network Box Camera·Quick Operation Guide Table of Contents 1 Appearance Description ................................................................. 8 2 Installation .................................................................................... 12 2.1 Ceiling Mounting ........................................................... 13 2.2 Wall Mounting .............................................................. 16 2.3 Installing the SD Card ....................................................
Network Box Camera·Quick Operation Guide 1 Appearance Description The overview of the box camera is shown below: Figure 1-1 Overview (1) The overview of the components and the interface are shown below: 1 4 2 3 5 Figure 1-2 Overview (2) 8
Network Box Camera·Quick Operation Guide The interfaces on the rear panel are shown below: 9 8 10 6 11 7 18 17 15 16 13 14 12 Figure 1-3 Overview (3) Table 1-1 Description No. Description No.
Network Box Camera·Quick Operation Guide No. Description No. Description 5 Auto-iris Interface 6 LAN(PoE) 7 Power Outlet 8 Reset 9 Micro SD Card Slot 10 Video Out 11 Grounding 12 Alarm Out 13 RS-232 14 RS-485 15 Alarm In 16 Audio Out 17 ABF 18 Audio In Only the models with “A” in its suffix support ABF function. To reset the camera default parameters, you need to press and hold the RESET button and power on the camera.
Network Box Camera·Quick Operation Guide Table 1-2 Pins No. DC-driven 1 Damp- 2 Damp+ 3 Drive+ 4 Drive- Power, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+ and Drive- pins are used when the auto-iris is driven by DC.
Network Box Camera·Quick Operation Guide 2 Installation Before you start: Make sure the device in the package is in good condition and all the assembly parts are included. Make sure all the related equipment is power-off during the installation. Check the specification of the products for the installation environment. Make sure the power supply is matched with your required voltage to avoid damage.
Network Box Camera·Quick Operation Guide ● Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera may reflect back into the lens causing reflection. ● The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS. Fasten the dome cover to camera body so that the foam ring and the dome cover are attached seamlessly. 2.1 Ceiling Mounting Steps: 1.
Network Box Camera·Quick Operation Guide 2. Fit the lens (not supplied) to the camera and rotate it to get it tightened. Install the adapter ring to the lens interface if a C-mount lens is used. A manual-iris lens can be directly installed to the camera without plugging the power cable of the auto-iris to the auto-iris interface. 3. Plug the auto-iris cable to the auto-iris interface. Figure 2-2 Install the Lens 4.
Network Box Camera·Quick Operation Guide 5. Adjust the surveillance angle. 1). Loosen the pan nut to adjust the pan angle [0°-360°]. 2). Loosen the knob on the ceiling mount to adjust the tilt angle [0°-90]. 6. Adjust the Lens 1). Connect the VIDEO OUT interface of the camera to the debugging monitor. 2). Adjust the Zoom Lever and Focus Level to obtain a perfect image on the monitor.
Network Box Camera·Quick Operation Guide 2.2 Wall Mounting Steps: 1. Install the lens (not supplied) to the camera and rotate it to get it tightened. 2. Plug the auto-iris cable to the auto-iris interface. Figure 2-4 Install the Lens 3. Loosen the lock screw on the mount and remove the tilt adjust table from the wall mount.
Network Box Camera·Quick Operation Guide Tilt Adjust Table Lock Screw Figure 2-5 Remove the Tilt Adjust Table 4. Fit the removed tilt adjust table to the camera, and fix it with two screws. Figure 2-6 Install the Tilt Adjust Table 5. Secure the wall mount to the wall with the supplied expansion screws.
Network Box Camera·Quick Operation Guide Figure 2-7 Install the Wall Mount 6. Install the camera to the wall mount and tighten the two lock screws. 7. Adjust the surveillance angle. 1). Loosen the pan nut to adjust the pan angle [0 °-360°]. 2). Loosen the knob on the ceiling mount to adjust the tilt angle [0°-±45°]. 8. Adjust the Lens 1). Connect the VIDEO OUT interface of the camera to the debugging monitor. 2). Adjust the focus level to obtain a perfect image on the monitor.
Network Box Camera·Quick Operation Guide Tilt Adjust Screw Pan Adjust Screw Figure 2-8 Adjust the Surveillance Angle 2.3 Installing the SD Card Insert the SD card to the SD card slot to get it installed. Push the inserted SD card slightly to get it sprung by its built-in springing to remove it.
Network Box Camera·Quick Operation Guide 3 Setting the Network Camera over the LAN Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or PCNVR software to search and change the IP of network camera. The following figure shows the cable connection of network camera and PC: Figure 3-1 Wiring over LAN Set the IP address of the camera for accessing via LAN. Steps: 1.
Network Box Camera·Quick Operation Guide Use PCNVR software and to list the online devices. Please refer to the user manual of PCNVR client software for detailed information. 2. Change the IP address and subnet mask to the same subnet as of your PC.
Network Box Camera·Quick Operation Guide Figure 3-2 Search Online Devices Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device list manually. The newly searched devices will be added to the list.
Network Box Camera·Quick Operation Guide You can click or on each column heading to order the information; you can click to show the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. Modify device information Steps: 1). Select the device to be modified in the device list as shown in Figure 3-3. The network parameters of the device will be displayed in the Modify Network Parameters panel on the right side as shown in Figure 3-4. 2).
Network Box Camera·Quick Operation Guide Figure 3-4 Modify Network Parameters 3. Enter the IP address of network camera in the address field of the web browser to view the live video. The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”. For accessing the network camera from different subnets, please set the gateway for the network camera after you log in.
Network Box Camera·Quick Operation Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version Steps: 1. Open the web browser. 2.
Network Box Camera·Quick Operation Guide Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
Network Box Camera·Quick Operation Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in (1) 27
Network Box Camera·Quick Operation Guide Figure 4-4 Install Plug-in (2) 6. Reopen the web browser after the installation of the plug-in and repeat steps 2-4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.
