User Manual of Analog Speed Dome
© Hikvision
39
AUX
AUX1 CLOSE
DWELL TIME 2
AUX2 OPEN
DWELL TIME 0
BACK EXIT
Figure 3-26 Configure the AUX Output
2. Click IRIS+ to edit the status of the auxiliary outputs. You can set the alarm output type as OPEN
(normally open) and CLOSE (normally closed).
Note: there are 2 auxiliary outputs configurable.
3. Move the cursor to DWELL TIME to set the duration of the auxiliary output signal. The
configurable rage is 0~60 seconds.
4. Link the auxiliary output to the configured alarm.
Steps:
(1) Enter MAIN MENUS > DOME SETTINGS > ALARMS > ALARM SETTING and choose the alarm
number that you want to link the auxiliary output to.
(2) Move the cursor to AUX and click IRIS+ to configure the auxiliary output to the alarm. You
can choose NONE to disable auxiliary alarm outputs, choose 1 to active AUX 1 or choose 2 to
active AUX 2.
3.7 Others
3.7.1 Setting the Language of the Menu
Enter MAIN MENUS > LANGUAGE, you can set the language of the on-screen display menu in
Chinese or in English.
3.7.2 Configuring Dome Authentication
Purpose:
You can modify the password and enable/disable the password protection to prevent unauthorized
settings of the speed dome. After you set and enable the password, you need to input the password
every time you call preset 95 to enter the menu.
Steps:
1. Move the cursor to enter the password modification submenu:
MAIN MENU > DOME SETTINGS > PASSWORD > EDIT PASSWORD
