User Manual of Analog Speed Dome

3.6.1 Configuring Alarm Input and Linked Actions

Purpose:

This section explains how to configure the speed dome to respond to alarm events with alarm

linked actions, such as calling presets, patrols, patterns, scanning, etc.

Steps:

1. Move the cursor to enter the alarm configuration submenu:

MAIN MENUS > DOME SETTINGS > ALARMS > ALARM SETTING

ALARMS

ALARM RESUME ON

ALARM SEQUENCE 5

ALARM REST DELAY 5

ALARM SETTING

BACK EXIT

ALARM SETTING

ALARM NUM 1

PRIORITY HIGH

ALARM ACT NONE

AUX NONE

ALARM INPUT OPEN

BACK EXIT

Figure 3-25 Alarm Configuration Menu

2. Choose the alarm number.

Steps:

(1) Move the cursor to ALARM NUM and click the IRIS+ to enter edit mode.

(2) Click the up and down direction buttons to select the number of the alarm which is to be

configured.

(3) Click IRIS+ again to confirm and exit edit mode of this column.

Note: You can configure up to 7 alarms.

3. Configure the alarm input.

Steps:

(1) Move the cursor to ALARM INPUT and click the IRIS+ to enter edit mode.

(2) Click the up and down direction buttons to set the input status. You can configure it as OPEN

(Normally open), CLOSE (Normally closed) or OFF (disable the alarm input).

(3) Click IRIS+ again to confirm.

Note: If you set the status as OPEN, alarm will be triggered by high electricity level; if you set the

status as CLOSE, alarm will be triggered by low electricity level; if you set the status as OFF, it

will be triggered when this input channel is shut off.

4. Configure the alarm linkage action.

You can specify the linked action when an alarm occurs. On the ALARM ACT submenu, you can

set the alarm action as preset from 1 to 8, pattern from 1 to 4, patrol from 1 to 8, panning scan,

tilting scan, random scan, frame scan, panoramic scan, day mode, night mode or none. You can

also set the alarm output for the alarm. Please refer to Section 3.6.3 Configuring Auxiliary

Alarm Output for details.

5. Configure alarm priority.

Enter the PRIORITY menu and set the alarm priority as HIGH, MID or LOW.
