NUM PRESET DWELL SPEED
1 0 6 30
2 0 6 30
3 0 6 30
4 0 6 30
5 0 6 30
6 0 6 30
7 0 6 30
DONE: OPEN QUIT:CLOSE
Figure 3-16 Edit the Patrol
(2) Click up/down direction buttons to choose the number and locate the preset to be edited.
(3) Click left/right direction buttons to position the cursor to the column of PRESET, DWELL and
SPEED. You can click the up/down direction buttons to set the value of preset number, dwell
time and patrol speed.
Note: The presets you set for a patrol should be the ones that have been pre-defined by
users. The dwell time (5-800 seconds selectable) is the time that the speed dome stays on a
certain preset; the patrol speed (level 1-40 selectable) is the scanning speed the speed dome
switching between the presets.
(4) Follow the above steps to define the other presets for the selected patrol. You can configure
up to 32 presets in sequence for a patrol. Press IRIS+ to save the new settings or press IRIS-
to cancel and return to the previous menu.
 Preview the patrol.
Move the cursor to PREVIEW and click IRIS+ to preview the current patrol. You can click IRS+
again to stop the preview.
 Call the defined patrol.
You can call the special presets to call the defined patrol. E.g. call preset 35 to call patrol 1.
Please refer to Section 2.3 to find the corresponding preset number for each patrol.
 Delete a patrol.
You can move the cursor to CLEAR PATH and click IRIS+ to delete the current patrol.
 Configuring the shortcut patrol.
Calling the system-defined preset 46 can enable the shortcut patrol. The patrol starts from the
number 1 preset to number 32 preset by default.
You can set the duration time in a preset scene by adjusting PATROL-D TIME. The value can be 5,
10, 20, 30 and 60s.
3.4.4 Configuring Patterns
Purpose:
A pattern is a memorized, repeatable series of pan, tilt, zoom and preset movements that can be
recalled by a command or automatically performed by a configured function (park, time task, and
power-up).
