Note: The preset position settings will be restricted by the limit stops if they are defined.
4. Call the presets.
You can select the preset number from the drop-down preset list in the control panel of the
encoder through a web browser, and click the arrow to call a user-defined or system-defined
preset.
5. Clear the preset settings.
Move the cursor to CLEAR PRESET and click IRIS+ to clear the settings of the current preset.
3.4.3 Configuring Patrols
Purpose:
A patrol is a scanning track specified by a group of user-defined presets. You can call a patrol to scan
the scenes automatically among the user-defined presets in sequence.
Steps:
 Move the cursor to enter patrol configuration submenu:
MAIN MENU > DOME SETTINGS > PATROLS
PATROLS
PATROL NUM 1
EDIT PATROL
PREVIEW
CLEAR PATH
PATROL_D TIME 30S
BACK EXIT
Figure 3-15 Patrol Configuration Menu
 Choose the patrol number.
Steps:
(1) Move the cursor to PATROLS NUM and click IRIS+ to enter edit mode.
(2) Click the up and down direction buttons to select the number of the patrol which is to be
configured.
(3) Click IRIS+ again to confirm the settings and exit edit mode of this column.
Note: Up to 8 patrols can be configured.
 Edit the patrol.
Steps:
(1) Move the cursor to EDIT PATROL and click IRIS+ to enter edit mode.
