4. Enable or disable the privacy mask function.

Move the cursor to BLANK STATUS. Click IRIS+ button to enter the editing mode and click the up

and down direction buttons to set it ON or OFF.

Note: If no privacy mask has been configured, you cannot set the status as ON.

5. Delete the privacy mask.

You can enter the CLEAR BLANK menu to delete the current privacy mask.

3.3.5 Configuring OSD Settings

Purpose:

You can configure the on-screen display of the dome name, PTZ control information, viewing

direction, etc.

 Display the dome title

Steps:

1. Enter the dome title setting menu:

MAIN MENUS > SET TITLE

2. Click IRIS+ to enter the editing mode.

3. Click FOCUS + to set it to ON.

4. Click IRIS+ again to confirm.

5. Exit the MAIN MENUS interface.

6. On the live view screen, call preset 11 twice within 5 seconds to enter the SET TITLE menu, as

shown in the following figure.

TITLE

CODE

TITLE

Figure 3-10 Set Dome Title

7. Click the left/right direction buttons to position the cursor to the characters of the title.

8. Get the codes for a specific character and enter each code (number) by calling the preset

number, i.e. calling presets 1-9 to enter number 1-9 respectively, and calling preset 10 to enter

number 0.

Note: You can get the codes of a specific character using the software we provided. For example, if

you want to display the word HALL as a part of the dome name, please follow below steps:

Steps:

(1) Enter HALL in the Title filed of the software, click OK, and you’ll see the corresponding

codes 0227-0220-0231-0231 listed for it.
