2. Click the left/right/up/down direction buttons to adjust the view angle.
3. Click IRIS+ button to confirm and exit.
 IR LED Parameters
IR PARAMETER
IR SENSITIVITY LOW
N/M LED CURRNT 2
FAR LED CURRNT 2
REFERENCE HEIGHT(M) N/A
REFERENCE ZOOM N/A
LED CONTROL AUTO
BACK EXIT
Figure 3-6 IR Parameter
 IR Sensitivity:
When the LED CONTROL mode is AUTO, the IR LEDs are turned on or off according to the
illumination of the scene. The IR SENSITIVITY is higher, the IR LEDs are turned on or off easier
when the illumination changes.
The IR SENSITIVITY can be set to LOW, MEDIUM or HIGH.
 LED Current:
Configure the N/M LED CURRENT and FAR LED CURRENT to adjust the brightness of NEAR,
MEDIUM and FAR LEDs. The brightness value ranges from 1 to 10.
 LED Control:
Configure the LED CONTROL to set the LED control mode. The LED control mode can be AUTO,
FAR(far irradiation distance LEDs) ON, M/F(medium and far irradiation distance LEDs) ON,
MID(medium irradiation distance LEDs) ON, M/N(medium and near irradiation distance LEDs)
ON and OFF.
Note: The IR function is supported by IR speed dome only.
 Fan parameter configuration
You can set the FAN CONTROL as ON or OFF.
 EIS (Electronic Image Stabilization) configuration
You can set the EIS FUNCTION as ON or OFF; and set the EIS LEVEL as 0-3.
Note: The selectable EIS levels vary depending on the camera models.
 Preset direct focus
You can set the preset direct focus function ON/OF on PRESET DFOCUS submenu.
 Protocol settings
You can set the PROTOCOL STATUS SET as ON or OFF, and set the PROTOCOL SET as AUTO
MATCH, PELCP-P, PELCO-D, Private-code, etc.
