If the SOFT ADDR is set to OFF, the hard address set by the DIP switch is the valid address of the
speed dome.
Task 2: Set the broadcast address of the speed dome.
When the BROADCAST ADDRESS is set to ON, the control devices with address 0 can control the
speed dome remotely regardless of the address of the speed dome.
With this function on, the control device with address 0 is capable of controlling all domes
connected to it. This function is usually for debugging.
 Soft baudrate settings
If the SOFT BAUD ACTIVE is set as ON, the soft baudrate is the valid baudrate for the speed dome,
with 2400, 4800, 9600 and 19200 selectable.
If the SOFT BAUD ACTIVE is set as OFF, the baudrate should be set by the DIP switch.
Note: After you enable/disable the soft baudrate, the speed dome will reboot automatically to
activate the settings.
 PELCO checksum
If the speed dome uses PELCO-P or PELCO-D protocol, you can set the PELCO CHECKSUM as ON for
improving the controlling effect.
 System time configuration
Steps:
(1) Move the cursor to SYS TIME using the direction buttons and click IRIS+ to enter.
(2) Click the left/right direction buttons to position the cursor on the specific item
(year/month/day or hour/minute/second) of which you want to change the value.
(3) Click the up/down direction buttons to increase/decrease the value.
(4) Click IRIS+ button to confirm and exit.
Y - M - D 07 01 18
H - M - S 15 33 25
DONE: OPEN
QUIT: CLOSE
Figure 3-5 Set the System Time
 Zero angle (initial position) configuration
Purpose:
You can define the initial position in the panning direction on the ZERO ANGLE submenu.
Steps:
1. Move the cursor to ZERO ANGLE using the direction buttons and click IRIS+ to enter.
