similar to the system information shown after the power-up action. Please refer to Section 2.1 for
more details.
Enter the system information display menu:
MAIN MENUS > SYS INFO
SYS INFO
TYPE XX- XXXXX-X
ADDRESS 0
COM FORMAT 0000,0,0
PROTOCOL XXXXX
VERSION 0. 00
HARDVERSION 0. 00
BUILD DATE 13 08 05
BACK EXIT
Figure 3-3 System Information
Notes:
 Information on this menu cannot be edited.
 The temperature refers to the internal temperature of the speed dome.
3.2.2 Configuring System Parameters
Purpose:
You can check and also edit the system information of software address, baud rate, system time, etc.
on the system information settings menu.
Enter the system information settings menu:
MAIN MENUS > DOME SETTINGS > SYS INFO SETTINGS
SYS INFO SETTINGS
SOFT ADDRESS 1
SOFT ADDR ACTIVE OFF
SOFT BAUD 2400
SOFT BAUD ACTIVE OFF
BROADCAST ADDRESS ON
PELCO CHECKSUM ON
SYS TIME
BACK EXIT
SYS INFO SETTINGS
ZERO ANGLE
DISPLAY SETTINGS
IR PARAMETER
FAN CONTROL N/A
EIS FUNCTION OFF
EIS LEVEL N/A
PRESET DFOCUS OFF
BACK EXIT
SYS INFO SETTINGS
PROTOCOL STATUS SET OFF
PROTOCOL SET AUTO MATCH
485CHECK SET AUTO
COAXITRON ACTIVE ON
POWER MEMORY 180S
BACK EXIT
Figure 3-4 System Information Settings
 Dome address settings
Task 1: Set the soft address of the speed dome.
If the SOFT ADDR is set to ON, the soft address is the valid address for connecting the speed
dome. The SOFT ADDRESS NUM ranges from 1 to 255;
