Note: For Manchester code control protocol, the system-defined presets with special functions are
shown as below:
Table 1-1 System-defined Presets of Manchester Code Control Protocol
Set Preset
No.
Function
Call Preset
No.
Function
65
Remote reboot
67
Auto-flip
66
Access main menu
70
Run Pattern 1
69
Stop recording pattern
71
Run Pattern 2
70
Record Pattern 1
72
Run Pattern 3
71
Record Pattern 2
72
Record Pattern 3
2.4 On-screen Displays
The speed dome supports following on screen displays:
Zoom: Identifies the amount of magnification. The format is ZXXX. XXX is the zoom amount.
Direction: Displays panning and tilting direction, with the format of NEXXX TXXX. The XXX following
NE indicates the degrees in north east direction, while the XXX following T indicates the degrees in
tilt position.
Time: Supports for time display.
Preset Title: Identifies preset being called.
